Installation instructions for part AXDI-GMLN11
REV. 1/20/2020 INSTAXDI-GMLN11
axxessinterfaces.com • metraonline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse,
and speed sense)
• Retains chimes through an onboard speaker
• Pre-wired AXSWC harness (AXSWC sold
separately)
•
Designed for non-amplified models, amplified
models, or when bypassing a factory amplifier
• Retains balance and fade
• Micro “B” USB updatable
INTERFACE FEATURES
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
APPLICATIONS
Connections to be made 2 ...................................................
Installing the AXDI-GMLN11 3 .............................................
Initializing the AXDI-GMLN11 3 ...........................................
Table of Contents
• AXDI-GMLN11 interface • AXDI-GMLN11 harness
INTERFACE COMPONENTS
CHEVROLET
Cobalt 2007-2010
HHR 2006-2011
Malibu 2008-2012
PONTIAC
G5 2007-2009
G6 2010
PONTIAC (CONT)
G6 (5th digit of VIN must
be a J, K, or L) 2009
Solstice 2006-2009
SATURN
Aura 2007-2009
Sky 2007-2009
AXDI-GMLN11
Connections to be made
From the AXDI-GMLN11 harness to the aftermarket radio:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
• Connect the wire to the amplifier turn on wire.Blue
• If the aftermarket radio has an illumination wire, connect the wire to it.Orange
• Connect the wire to the right front positive speaker output.Gray
• Connect the wire to the right front negative speaker output.Gray/Black
• Connect the wire to the left front positive speaker output.White
• Connect the wire to the left front negative speaker output.White/Black
• Connect the wire to the left rear positive speaker output.Green
• Connect the wire to the left rear negative speaker output.Green/Black
• Connect the wire to the right rear positive speaker output.Purple
• Connect the wire to the right rear negative speaker output.Purple/Black
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
12-pin pre-wired AXSWC harness:
• This harness is to be used along with the optional AXSWC (not included) to
retain steering wheel audio controls. If the AXSWC is not being used, disregard
this harness. If it will be used, please refer to the AXSWC instructions for radio
connections and programming.
Note: Disregard the harness that comes with the AXSWC.
• The following wire must be cut before programming the AXSWC:
• For the following vehicles cut the wire. If your vehicle is not Green/Orange
listed, do not cut anything:
CHEVROLET
Cobalt 2007-2010
HHR 2006-2011
Malibu 2008-2012
PONTIAC
G5 2007-2009
G6 2010
PONTIAC (CONT)
G6 (5th digit of VIN must
be a J, K, or L) 2009
Solstice 2006-2009
SATURN
Aura 2007-2009
Sky 2006-2009
AXDI-GMLN11
Initializing the AXDI-GMLN11
Attention! If the interface loses power for any reason, the following steps will need
to be performed again. Also, if installing an AXSWC connect it after you initialize and
test the interface/radio, with the key in the off position.
• Turn the key (or push-to-start button) to the ignition position and wait until the
radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the
off position, disconnect the interface, check all connections, reconnect the
interface, and then try again.
• Turn the key to the off position, and then to the accessory position. Test all
functions of the installation for proper operation, before reassembling the dash.
Installing the AXDI-GMLN11
With the key in the off position:
• Connect the AXDI-GMLN11 harness into the interface, and then to the wiring
harness in the vehicle.
Note: If using the AXSWC, connect it after you initialize and test the AXDI-
GMLN11, with the key in the off position.
