Seite 1/3
AXDCT-2
INSTALL ATION INSTRUCTI O N S
REV. 3/2/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The AXDCT-2 should be installed on a stereo’s speaker output wires or the
output wires on an factory amplier of up to 80 watts per channel. These
wires can be found behind the stereo in the dash, on the outside of an factory
amplifier, or on the input terminals on the factory speakers.
Wire Color & Function: The audio input wire colors are an EIA standard for car
stereo applications as follows:
Yellow - Battery +12v input †
Black - Ground input †
Blue - Remote +12v output †
These wires can be connected directly to the amplifier being installed.
Wires only required if a 12v amp turn-on is desired.
White - Left front (+) input
White/Black - Left front (-) input
Gray - Right front (+) input
Gray/Black - Right front (-) input
Black/White - Reference ground (-)
(Reference ground optional if noise is present)
Note: Be sure that all audio input connections are polarized or in phase with
each other. That is, the positive output wires from the audio source need to be
connected to the corresponding positive input wires of the AXDCT-2. The same
goes for the negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
AXDCT-2
INSTALL ATION INSTRUCTI O N S
REV. 3/2/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The AXDCT-2 is designed to convert 2 channels of speaker level audio
into 2 channels of line level audio. This allows for the installation of
line level products such as amplifiers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition this device will
also detect the presence of an audio signal and then generate a +12V
output (verified by an illuminated LED) that can be used to turn-on an
aftermarket amplifier.
Features:
80 Watts Maximum Input, Input Circuit Corrects Crossover Distortion
Commonly Found On Other Brands of LOCs, 6:1 Step Down with Variable
Output, Gold Flashed RCAs, Attractive & Durable Enclosure. The AXDCT-2
will shut off 60 seconds after no signal detected.
