AXBUCS-SB286V2
INSTALLATIO N I NS TRUC T IONS
REV. 2/24/20© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains the factory AUX-IN jack
• Retains the factory backup camera
• Includes an AXCSD-6V 12-to-6V step-down for the factory camera
• Pre-wired AXSWC harness (AXSWC sold separately)
INTERFACE COMPONENTS
• AXBUCS-SB286V2 harness • AXCSD-6V
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
AXBUCS-SB286V2
Subaru Legacy/Outback (without NAV, with Display radio†)
2013-2014
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must be
connected before cycling the ignition. Also, do not remove the factory radio with the key in the on position, or while
the vehicle is running.
† Display radio is a color display radio
AXBUCS-SB286V2
INSTALLATIO N I NS TRUC T IONS
REV. 2/24/20© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
K PNOWLEDGE IS OWER
Enhance your inst allation and fa brication skills by
enrolling in the most recognized a nd spect ed re
mobile elect nics school in our industry.ro
Log onto www.insta llerinstitute.com or call
800-354-6782 for mo informat ion and take st eps re
towa rd a bett er tomorrow.
®
Metra r ecommends MECP
certified technicians
Connections
Connect the wire to chassis ground, and also to the wire from the AXCSD-6V.Black Black
Connect the wire labeled "Camera Power 6V" to the wire from the AXCSD-6V.Red Blue/Red
If retaining steering wheel controls: connect the wire labeled “AXSWC 12V Accessory” to Red
accessory power.
Connect the wire to the reverse wire from the radio, and also to the Green/Purple Blue/White
wire from the AX CAM6V.
Connect the Yellow RCA jack to the backup camera input from the radio.
If retaining the factory AUX-IN jack, connect the and RCA jacks to the AUX input Red White
from the radio.
The following (2) wires are for aftermarket multimedia/navigation radios that require these wires
:
Connect the wire to the VSS/speed sense wire.Blue/Pink
Connect the Light Green wire to the parking brake wire.
Installation
1.
After the radio has been tested and verified working properly, remove the key from the ignition.
Connect the AXBUCS-SB286V2 harness to the wiring harness in the vehicle, then to the AXSWC.
2. Refer to the AXSWC instructions for radio connections and programming. Disregard the harness
that comes with the AXSWC.
