Seite 1/5
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/20/20
axxessinterfaces.com • metraonline.com
Axxess Integrate
Installation Instructions for AXBUCS-NI406V
INTERFACE FEATURES
• Pre-wired AXSWC harness (AXSWC sold separately)
• Retains the factory AUX-IN jack
• Retains the factory backup camera to an aftermarket radio
• Includes the AXCSD-6V 12-volt to 6-volt converter
AXBUCS-NI406V
Pre-wired AXSWC Harness
Nissan Maxima 2016-up(without amp)
INTERFACE COMPONENTS
AXBUCS-NI406V harness • AXCSD-6V 12-volt to 6-volt converter
Wire cutter • Crimping tool • Solder gunTape
• Connectors (example: butt connectors, bell caps, etc.)
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/20/20
axxessinterfaces.com • metraonline.com
Axxess Integrate
Installation Instructions for AXBUCS-NI406V
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most cognized and spect ed re re
mobile electronics s chool in our industry.
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo information a nd t ake st eps re
toward a bett er t omorrow.
Metra r ecommends MECP
certified technicians
Connections to be made
Connect the wire with a ring terminal to chassis ground.Black
Connect the wire of the AXCSD-6V wire to chassis ground.Black
• Connect the wire labeled "Camera Power 6V" to the wire Red Blue/Red
of the AXCSD-6V.
Connect the wire to the reverse wire of the aftermarket radio, Green/Purple
and also to the wire of the AXCSD-6V.Blue/White
• Connect the wire to the VSS/speed sense wire of the aftermarket radio Blue/Pink
(if applicable).
• Connect the wire to the parking brake wire of the aftermarket radioLight Green
(if applicable).
If retaining the factory AUX-IN jack, connect the & RCA jacks to Red White
the AUX input.
• Connect the Yellow RCA jack to the rear camera input of the aftermarket radio
.
12-pin pre-wired AXSWC harness:
This harness is to be used along with the optional AXSWC (not included) to
retain steering wheel audio controls. Please refer to the AXSWC instructions
for radio connections and programming.
Note: Disregard the harness that comes with the AXSWC.
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/20/20
axxessinterfaces.com • metraonline.com
Axxess Integrate
Instrucciones de instalación para AXBUCS-NI406V
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no
quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
CARACTERÍSTICAS DE LA INTERFASE
Arnés AXSWC precableado (el AXSWC se vende por separado)
• Retiene el conector de de labrica AUX-IN
• Retiene la cámara de reversa de fábrica de mercado secundario
• Incluye el AXCSD-6V 12 voltios al convertidor de 6 voltios
AXBUCS-NI406V
Arnés AXSWC pre-cableado
Nissan Maxima 2016 y mas(sin amp)
COMPONENTES DE LA INTERFASE
Arnés AXBUCS-NI406V • AXCSD-6V 12 voltios al convertidor de 6 voltios
• Cortacables • Ponchadora • Pistola soldadora • Cinta
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
HERRAMIENTAS REQUERIDAS
