© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
axxessinterfaces.com • metraonline.com
Axxess Integrate
REV. 1/28/20
Installation Instructions for AXBUCH-T36V
INTERFACE FEATURES
• Retains the factory backup camera to an aftermarket radio
• Allows an aftermarket camera to be added to the factory screen*
• Includes the AXCSD-6V 12-volt to 6-volt converter
* Display and navigation model radios only
INTERFACE COMPONENTS
• AXBUCH-T36V harness • AXCSD-6V 12-volt to 6-volt converter
AXBUCH-T36V
Toyota Backup Camera Retain/Add-On
2013-2016
SCION
FR-S 2016
iM 2016
tC 2016
TOYOTA
4-Runner 2014-2016
4-Runner (without NAV) 2013
Avalon 2015-2016
Camry 2014-2016
Corolla 2014-2016
Highlander 2014-2016
Prius C 2015
Prius V 2015
Rav-4 2015-2016
Rav-4 (after build
date Nov. 2013) 2014
Sienna 2015
Sequoia 2014-2016
Tacoma 2014-2016
Tundra 2014-2016
Venza 2015-2016
• Cutting tool • Tape • Crimping tool
• Connectors (example: butt connectors, bell caps, etc.)
APPLICATIONS
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
axxessinterfaces.com • metraonline.com
Axxess Integrate
REV. 1/28/20
Installation Instructions for AXBUCH-T36V
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most recogniz ed and spected re
mobile elect nics school in our indust ry.ro
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo information a nd t ake st eps re
toward a bett er t omorrow.
®
Metra r ecommends MECP
certified technicians
Connections to be made
The AXBUCH-T36V can be connected two different ways
To retain the factory backup camera to an aftermarket radio:
•
Connect the wire to chassis ground and also to the wire of the AXCSD-6VBlack Black
.
• Connect the Yellow Blue/Red wire to the wire of the AXCSD-6V.
• Connect the reverse wire from the aftermarket radio, to the reverse signal in the
vehicle, and also to the wire of the AXCSD-6V.Blue/White
• Connect the male Yellow RCA jack to the rear camera input of the aftermarket radio.
• Disregard the loose wire, it will not be used in this application.Green/Purple
To allow an aftermarket camera to be added to the OEM screen:
• Connect the wire to the ground wire of the aftermarket camera.Black
• Connect the power wire of the aftermarket camera to accessory power.
• Tape off and disregard the Yellow wire, it will not be used in this application.
• Connect the female Yellow RCA jack to the aftermarket camera.
• The AXCSD-6V 12-volt to 6-volt converter will not be used in this application.
The following (2) steps are only required if
a wire is present in the factory harnessnot
.
•
If a wire is not present in pin-2 of the 28-
pin connector of the factory radio, unplug
the connector, then insert the metal pin
of the loose wire into it. Green/Purple
Connect the harness back into the radio
.
• Connect the other end of the loose
Green/Purple wire to the reverse
wire of the vehicle.
14 13 12 11 10 9 8 7 6 5 3 2 4 1
28 27 26 25 24 23 22 21 20 19 18 17 16 15
This is the wire view of the connector in the vehicle
28 Pin Harness
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
axxessinterfaces.com • metraonline.com
Axxess Integrate
REV. 1/28/20
Instrucciones de instalación para AXBUCH-T36V
CARACTERÍSTICAS DE LA INTERFASE
• Retiene la cámara de reversa de fábrica para un radio de mercado secundario
• Permite que se añada una cámara de mercado secundario a la pantalla de fábrica*
• Incluye el AXCSD-6V de 12 voltios al convertidor de 6 voltios
* Sólo Pantalla y modelo de navegación radios
COMPONENTES DE LA INTERFASE
• Arnés AXBUCH-T36V • AXCSD-6V de 12 voltios al convertidor de 6 voltios
AXBUCH-T36V
Retener/Añadir cámara de reversa de Toyota
2013-2016
• Herramienta de corte • Cinta • Ponchadora
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
APLICACIONES
HERRAMIENTAS REQUERIDAS
SCION
FR-S 2016
iM 2016
tC 2016
TOYOTA
4-Runner 2014-2016
4-Runner (sin NAV) 2013
Avalon 2015-2016
Camry 2014-2016
Corolla 2014-2016
Highlander 2014-2016
Prius C 2015
Prius V 2015
Rav-4 2015-2016
Rav-4 (después la fecha de
construcción Nov 2013) 2014
Sienna 2015
Sequoia 2014-2016
Tacoma 2014-2016
Tundra 2014-2016
Venza 2015-2016
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no
quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
