AXBUCH-NS
INSTALL ATION INSTRUCTI O N S
REV. 12/11/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INTERFACE FEATURES
• Allows an aftermarket camera to be added to the factory 4.3-inch color display radio.
INTERFACE COMPONENTS
• AXBUCH-NS harness
TOOLS REQUIED
• Cutting Tool • Tape • Crimping Tool
• Connectors (example: butt connectors, bell caps, etc.)
Nissan Rear-View Camera Add-On to OEM 2010-Up
NISSAN (with 4.3-inch color display radio)
Altima 2010-2015
Frontier 2013-2015
Juke 2015
Leaf 2013-2015
Quest (without Bose) 2011-Up
Rogue 2011-2015
Rogue Select 2014-2015
Sentra 2010-2015
Titan 2013-2015
Versa 2014-2015
Versa Note 2014-2015
APPLICATIONS
Connections to be made
Connect the wire to the ground wire of the aftermarket camera.Black
Connect the Yellow wire to the power wire of the aftermarket camera.
Connect the female Yellow RCA jack to the aftermarket camera.
AXBUCH-NS
REV. 12/11/19© COPYRIGHT 2019 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INSTRUCCIONES DE INSTALACIÓN
COMPONENTES DE LA INTERFASE
• Arnés AXBUCH-NS
HERRAMIENTAS REQUERIDAS
• Herramienta de corte • Cinta • Ponchadora
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
Nissan Cámara de Visión Trasera Add-On para OEM 2010 y Mas
NISSAN
(con 4.3 pulgadas pantalla a color de radio)
Altima 2010-2015
Frontier 2013-2015
Juke 2015
Leaf 2013-2015
Quest (without Bose) 2011-Up
Rogue 2011-2015
Rogue Select 2014-2015
Sentra 2010-2015
Titan 2013-2015
Versa 2014-2015
Versa Note 2014-2015
APLICACIONES
Conexiones que se deben hacer
Conecte el cable al cable de tierra de la cámara de mercado secundario.negro
Conecte el cable al cable de energía de la cámara de mercado secundario.amarillo
Conecte el conector RCA hembra a la cámara de mercado secundario.amarillo
CARACTERÍSTICAS DE LA INTERFAZ
• Permite que se añada una cámara de mercado secundario al
fábrica de 4.3 pulgadas pantalla a color de radio.
