© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
axxessinterfaces.com • metraonline.com
Axxess Integrate
REV. 1/28/20
Installation Instructions for AXBUCH-MI6V
INTERFACE FEATURES
• Retains the factory backup camera to an aftermarket radio
• Allows an aftermarket camera to be added to the factory screen
• Includes the AXCSD-6V 12-volt to 6-volt converter
INTERFACE COMPONENTS
• AXBUCH-MI6V harness • AXCSD-6V 12-volt to 6-volt converter
AXBUCH-MI6V
Mitsubishi Backup Camera Retain/Add-On
2014-Up
MITSUBISHI
Lancer 2014-Up
Lancer Sportback 2014-Up
Outlander 2014-Up
Outlander Sport 2014-Up
• Wire cutter • Crimping tool • Solder gun • Tape
• Connectors (example: butt connectors, bell caps, etc.)
APPLICATIONS
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
axxessinterfaces.com • metraonline.com
Axxess Integrate
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/28/20
Installation Instructions for AXBUCH-MI6VInstallation Instructions for AXBUCH-MI6V
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most recogniz ed and spected re
mobile elect nics s chool in our industry.ro
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo information and t ake steps re
toward a bett er t omorrow.
®
Metra r ecommends MECP
certified technicians
Connections to be made
The AXBUCH-MI6V can be connected two different ways
To retain the factory backup camera to an aftermarket radio:
Connect the wire to chassis ground, and also to the wire of the AXCSD-6V.Black Black
Connect the Yellow wire to battery power.
Connect the wire to the wire of the AXCSD-6V.Red Blue/Red
Connect the wire to the reverse wire of the aftermarket radio,Green/Purple
and also to the wire of the AXCSD-6V. Blue/White
Connect the male Yellow RCA jack to the rear camera input of the aftermarket radio.
To allow an aftermarket camera to be added to the OEM screen:
Connect the wire to the ground wire of the aftermarket camera.Black
Connect the Yellow wire to battery wire of the aftermarket camera.
Connect the female Yellow RCA jack to the aftermarket camera.
The AXCSD-6V 12-volt to 6-volt converter will not be used in this application.
axxessinterfaces.com • metraonline.com
Axxess Integrate
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/28/20
Instrucciones de instalación para AXBUCH-MI6V
CARACTERÍSTICAS DE LA INTERFASE
• Retiene la cámara de reversa de fábrica para un radio de mercado secundario
• Permite que se añada una cámara de mercado secundario a la pantalla de equipo original
• Incluye el AXCSD-6V de 12 voltios al convertidor de 6 voltios
COMPONENTES DE LA INTERFASE
• Arnés AXBUCH-MI6V • AXCSD-6V 12 voltios al convertidor de 6 voltios
AXBUCH-MI6V
Retener/añadir mara de reversa de Mitsubishi
2014 y Mas
MITSUBISHI
Lancer 2014 y Mas
Lancer Sportback 2014 y Mas
Outlander 2014 y Mas
Outlander Sport 2014 y Mas
• Cortacables • Ponchadora • Pistola soldadora • Cinta
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
APLICACIONES
HERRAMIENTAS REQUERIDAS
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no
quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
