Seite 1/5
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
axxessinterfaces.com • metraonline.com
Axxess Integrate
REV. 1/28/20
Installation Instructions for AXBUCH-HK1
INTERFACE FEATURES
• Retains the factory back-up camera to an aftermarket radio
• Allows an aftermarket camera to be added to the factory screen
INTERFACE COMPONENTS
AXBUCH-HK1 harness
AXBUCH-HK1
Hyundai / Kia (with NAV)
2014-2017
HYUNDAI
Elantra 2017
Elantra GT 2016-2017
Genesis Sedan 2016
Santa Fe 2017
Santa Fe Sport 2017
Sonata 2015-2017
HYUNDAI (CONT)
Tucson 2016-2017
Veloster 2016-2017
KIA
Cadenza 2017
Forte 2017
Niro 2017
KIA (CONT)
Optima 2016-2017
Sedona 2015-2017
Sorento 2016-2017
Soul 2014-2017
Sportage 2017
• Wire cutter • Crimping tool • Solder gun • Tape
• Connectors (example: butt connectors, bell caps, etc.)
APPLICATIONS
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
axxessinterfaces.com • metraonline.com
Axxess Integrate
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/28/20
Installation Instructions for AXBUCH-HK1
K PNOWLEDGE IS OWER
Enhance your installat ion and fabrica tion skills by
enrolling in the most recogniz ed and spected re
mobile elect nics s chool in our industry.ro
Log ont o www.installerinstit ute.com or call
800-354-6782 for mo information and t ake steps re
toward a bett er t omorrow.
®
Metra r ecommends MECP
certified technicians
Connections to be made
The AXBUCH-HK1 can be connected two different ways
To retain the factory back-up camera to an aftermarket radio:
Connect the wire to chassis ground.Black
Connect the wire to accessory power.*Red
Connect the male Yellow RCA jack to the rear camera input of the aftermarket radio.
* It is highly recommended to use the AXCSD-6V (sold separately) to provide the
camera with the proper voltage.
To allow an aftermarket camera to be added to the OEM screen:
Connect the wire to the aftermarket cameras ground wire.Black
Connect the power wire of the aftermarket camera to accessory power.
Connect the female Yellow RCA jack to the aftermarket camera.
Tape off and disregard the following (1) wire, it will not be used in this application: Red.
Note: Disregard the loose Green/Purple wire, it will not be used in this application.
axxessinterfaces.com • metraonline.com
Axxess Integrate
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/28/20
Instrucciones de instalación para AXBUCH-HK1
CARACTERÍSTICAS DE LA INTERFASE
• Retiene la cámara de reversa de fábrica para un radio de mercado secundario
• Permite que se añada una cámara de mercado secundario a la pantalla de equipo original
COMPONENTES DE LA INTERFASE
Arnés AXBUCH-HK1
AXBUCH-HK1
Hyundai / Kia (con NAV)
2014-2017
• Cortacables • Ponchadora • Pistola soldadora • Cinta
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
HERRAMIENTAS REQUERIDAS
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no
quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
HYUNDAI
Elantra 2017
Elantra GT 2016-2017
Genesis Sedan 2016
Santa Fe 2017
Santa Fe Sport 2017
Sonata 2015-2017
HYUNDAI (CONT)
Tucson 2016-2017
Veloster 2016-2017
KIA
Cadenza 2017
Forte 2017
Niro 2017
KIA (CONT)
Optima 2016-2017
Sedona 2015-2017
Sorento 2016-2017
Soul 2014-2017
Sportage 2017
APLICACIONES
