Installation Instructions for AXBUCH-CH1
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/20/20
axxessinterfaces.com • metraonline.com
Axxess Integrate
FEATURES
• Retains the factory back-up camera to an aftermarket radio.
INTERFACE COMPONENTS
AXBUCH-CH1 harness
AXBUCH-CH1
Chrysler Backup Camera Retention
2011-2016
CHRYSLER
300 2011-2014
DODGE
Charger 2011-2014
Dart 2014*
Journey 2011-2016
APPLICATIONS
* With premium amp, at the tuner brain behind the glove box.
TOOLS REQUIED
• Cutting Tool • Tape • Crimping Tool
• Connectors (example: butt connectors, bell caps, etc.)
Connections to be made
Connect the wire to chassis ground. Black
Connect the female Yellow RCA jack to the aftermarket radios backup camera input.
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 1/20/20
Instrucciones de instalación para AXBUCH-CH1
axxessinterfaces.com • metraonline.com
Axxess Integrate
CARACTERÍSTICAS
• Retiene la cámara del respaldo fábrica para una radio no original.
COMPONENTES DE LA INTERFASE
Arnés AXBUCH-CH1
AXBUCH-CH1
Chrysler Retención de la Cámara de Reserva
2011-2016
CHRYSLER
300 2011-2014
DODGE
Charger 2011-2014
Dart 2014*
Journey 2011-2016
APLICACIONES
* Con amplificador de alta calidad, en el sintonizador de cerebro detrás de la guantera.
HERRAMIENTAS REQUERIDAS
• Herramienta de corte • Cinta • Ponchadora
• Conectores (ejemplo: conectores de extremo, de campana, etc.)
Conexiones que se deben hacer
Conecte el cable a la tierra del chasís. negro
Conecte el conector RCA a la entrada de la cámara de reserva radio no originalhembra amarillo
.
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de clima y especialmente
las luces del indicador de las bolsas de aire deben estar conectados antes ciclar la ignición. Además, no
quite el radio de fábrica con la llave en la posición o de encendido ni con el vehículo funcionando.
