AXADCT-4
INSTALL ATION INSTR UCTIONS
REV. 4/27/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
Wire Color & Function: The audio and power input wire colors are an EIA standard for car
stereo applications as follows.
INPUT HARNESS POWER HARNESS
White LEFT Front (+) Input Yellow BATTERY +12V Input
White/Black LEFT Front (-) Input POWER (-) GROUND InputBlack
Gray RIGHT Front + Input REMOTE +12V OutputBlue
Gray/Black RIGHT Front (-) Input Reference Ground(-)Black/White
Green LEFT Rear (+) Input
Green/Black LEFT Rear (-) Input
Purple RIGHT Rear (+) Input
Purple/Black RIGHT Rear (-) Input
OUTPUT HARNESS
White LEFT Front (+) Output LEFT Rear (+) OutputGreen
White/Black LEFT Front (-) Output LEFT Rear (-) OutputGreen/Black
Gray RIGHT Front + Output RIGHT Rear (+) OutputPurple
Gray/Black RIGHT Front (-) Output RIGHT Rear (-) OutputPurple/Black
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AXADCT-4. The same goes for the negative audio
wires. Failure to do this will result in poor bass response and low quality audio.
Adjusting the AXADCT-4 for maximum performance: After completing all of the necessary
connections, turn the AXADCT-4 adjustment pots all of the way down by rotating them
completely counter-clockwise. Now, turn the stereo system on and adjust the main volume
control on the stereo to approximately 3/4 maximum volume. Select one of the adjustment
pots on the AXADCT-4 and turn it slowly clockwise until you notice audio distortion and then
stop. Turn the remaining pots to the same position as the previously adjusted pot. The audio
set-up of the AXADCT-4 is now complete and ready to be enjoyed.
AXADCT-4
INSTALL ATION INSTR UCTIONS
REV. 4/27/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
A 4 Channel Adjustable, Line Output Converter (LOC) with Built-in Amplifier Remote
Generator
The AXADCT-4 is designed to convert 4 channels of speaker level audio into 4 channels
of line level audio that can be used by OEM amplifiers. It can also be used with OEM
radios to add aftermarket amplifiers. This device will also detect the presence of an
audio signal and then generate a +12V output (verified by an illuminated LED) that can
be used to turn-on an aftermarket amplifier.
Features & Specifications: The AXADCT-4 is able to handle 80 watts per channel
continuous input without over heating. The input circuitry is designed to correct the
crossover distortion commonly found on standard LOCs while providing a high to low
level step down of 6:1. Output audio level is infinitely adjustable using the onboard,
high quality potentiometers. The remote output or amplifier trigger is rated at 500mA
(+12V) and will easily handle an outboard relay if additional current is needed. The
remote output will trigger instantaneously when the AXADCT-4 detects a DC voltage
on the white, left + audio input wire above 5V or a very low audio signal. It will shut
off 60 seconds after no signal is detected.
Installation: The AXADCT-4 should be installed on a stereo’s speaker output wires or
the output wires on an OEM amplifier of up to 80 watts per channel. These wires can
be found behind the stereo in the dash, on the output of an OEM amplifier, or on the
input terminals on the OEM speakers. Please refer to the wiring diagram for the input
connection details.
INSTALLATION INSTRUCTIONS
