Seite 1/8
AXABH-CH4
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 2/23/23 INSTAXABH-CH4
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Amplifier locations ................................................2
Connections
22-Pin Harness ................................................3-6
10-Pin Harness .................................................7-8
Chrysler Amplifier Bypass Harness 2015-Up
Refer to the following pages for the vehicle specific instructions
for wiring connections. Wiring connections vary per vehicle. Please
note that there are (2) different wiring harnesses included, and the
instructions for each harness will be on a different page. *
If it’s uncertain whether the vehicle contains a specific speaker or not,
test the wires with a tone generator, or check to see if the factory
wires are populated on the vehicle side. Alternatively, the wires can
be tested for impedance with a multimeter.
APPLICATIONS
Alfa Romeo
Giulia 2017-2018
Stelvio 2018
Chrysler
300* 2016-Up
Pacifica 2017-2018
Dodge
Challenger*** 2016-Up
Charger* 2016-Up
Durango SRT 2018-Up
Viper 2016-2018
Jeep
Cherokee
†
2019-Up
Gladiator 2020-Up
Grand Cherokee* 2015-Up
Wrangler (JL body type) 2018-Up
Ram
Ram 1500 (exclude Classic)* 2019
Ram 1500 (exclude Classic)** 2019
* With Premium amp
** With Premium Plus amp
*** With Mid-line amp
†
With Active Noise Control (ANC)
* Excluding Jeep Wrangler
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the
ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
2
AMPLIFIER LOCATIONS
Make/Model Amp Location
Alfa Romeo
Guilia 2017-2018 Unknown
Stelvio 2018 Unknown
Chrysler
300 2016-Up Driver kick, left of steering column
Pacifica 2017-2018 Behind glovebox
Dodge
Challenger 2016-Up Driver kick, left of steering column
Charger 2016-Up Driver kick, left of steering column
Durango SRT 2018-Up Behind left rear quarter panel
Viper 2016-2018 Rear, luggage compartment (under floor)
Jeep
Cherokee
†
2019-Up Behind glove box
Gladiator 2020-Up Driver kick, left of steering column
Grand Cherokee 2015-Up Driver rear quarter, above wheel well
Wrangler (JL body type) 2018-Up Driver kick, left of steering column
Ram
1500 (excluding Classic) 2019-Up Under driver’s seat
† With Active Noise Control (ANC)
3
REV. 2/23/23 INSTAXABH-CH4
CONNECTIONS
Alfa Romeo
Giulia 2017-2018
Stelvio 2018
Green Left Front Tweeter +
Green/Black Left Front Tweeter -
Purple Right Front Speaker +
Purple/Black Right Front Speaker -
Orange Right Front Speaker +
Orange/Black Right Front Speaker -
Red Right Front Tweeter +
Red/Black Right Front Tweeter -
Yellow Center Instrument Panel Speaker +
Yellow/Black Center Instrument Panel Speaker -
Black Subwoofer 1 +
Black/White Subwoofer 1 -
Brown Left Front Speaker +
Brown/Black Left Front Speaker -
Blue Left Front Speaker +
Blue/Black Left Front Speaker -
22-Pin harness:
Chrysler
300* 2016-Up
Dodge
Charger* 2016-2018
Ram
1500 (excluding Classic)** 2019-Up
Green Left Rear Door Speaker +
Green/Black Left Rear Door Speaker -
Purple Right Rear Door Speaker +
Purple/Black Right Rear Door Speaker -
Orange Left Rear Speaker +
Orange/Black Left Rear Speaker -
Red Right Rear Speaker +
Red/Black Right Rear Speaker -
Yellow Center Instrument Panel Speaker +
Yellow/Black Center Instrument Panel Speaker -
Black Right Rear Tweeter +
Black/White Right Rear Tweeter -
Brown Left Rear Tweeter +
Brown/Black Left Rear Tweeter -
Blue Subwoofer +
Blue/Black Subwoofer -
22-Pin harness:
* With Premium amp
** With Premium Plus amp
