AX-VW93-CAM
INSTALL ATION IN STR UC TI ON S
REV. 3/1/18© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
AX-VW93-CAM
Volkswagen Golf (MK VII)
Camera Retention Interface
2012*
Connections to be made
Connect the wire to chassis ground.Black
Connect the wire to accessory power.Red
Connect the wire to reverse power (switched).Green
Connect the Yellow RCA jack to the aftermarket backup camera.
Installing the Interface
Remove the main connector from the radio, then connect the
male
plug
from the
AX-VW93-CAM
into the radio.
Connect the
male
factory connector into the
female
plug from the
AX-VW93-CAM
.
Connect the
AX-VW93-CAM harness
into the AX-VW93-CAM interface.
Test for correct operation.
• Allows a camera to be added to the factory radio
• Plug-and-play, no cutting of wires required
• Designed for NTSC cameras
• Auto switch in reverse gear
INTERFACE FEATURES
* For vehicles with Composition Media (MIB), Discovery Pro (MIB), Composition
Media (MIB STD2), Discover Media (MIB STD2).
* Vehicle must have an OPS (Optical Parking Sensor) head unit.
* Not compatible with: 3Q0035820A, 3Q0035820, 3Q0035819A, 3Q0035819,
3Q0035812, 5G0035820A, 5G0035820, 5G0035819A, 5G0035819, 5G0035812.
* For Professional installation ONLY, requires specialist equipment and knowledge to
program vehicle on-board settings to enable camera operation.
* Camera must be activated via VCDS. Head unit must be coded.
AX-VW93-CAM
REV. 3/1/18© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
INSTRUCCIONES DE INSTALACIÓN
AX-VW93-CAM
Volkswagen Golf (MK VII)
Interfase de Retención de la Cámara
2012*
Conexiones que se deben hacer
Conecte el cable a la tierra del chasís.negro
Conecte el cable a la alimentación de accesorios.rojo
Conecte el cable para invertir la potencia (cambiado).verde
Conecte la toma RCA a la cámara de reversa del mercado secundarioamarilla
.
Instalación de la Interfase
Retire el conector principal de la radio, luego conecte el enchufe
macho
del
AX-VW93-CAM
a la radio.
Conecte el conector de fábrica
macho
en el enchufe
hembra
del AX-VW93-CAM.
Conecte el
arnés AX-VW93-CAM
en la interfase AX-VW93-CAM.
Prueba de funcionamiento correcto.
• Permite que la cámara de fábrica se use con una radio de
mercado secundario
• Plug-and-play, no requiere corte de cables
• Diseñado para cámaras NTSC
• Cambio automático en marcha atrás
CARACTERÍSTICAS DE LA INTERFASE
* Para vehículos con Composition Media (MIB), Discovery Pro (MIB), Composition
Media (MIB STD2), Discover Media (MIB STD2).
* El vehículo debe tener una unidad principal OPS (Optical Parking Sensor).
* No es compatible con: 3Q0035820A, 3Q0035820, 3Q0035819A, 3Q0035819,
3Q0035812, 5G0035820A, 5G0035820, 5G0035819A, 5G0035819, 5G0035812.
* SOLAMENTE para instalación profesional, se requieren equipos y conocimientos
especializados para programar los ajustes de a bordo del vehículo para permitir
el funcionamiento de la cámara.
* La cámara debe ser activada a través de VCDS. La unidad principal debe estar
codificada.
