Seite 1/8
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AX-VW903
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 5/11/18 INSTAX-VW903
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
TABLE OF CONTENTS
Connections to be made .......................................2
Installing the AX-VW903 interface .......................3
Programming the ASWC-1 interface .....................3
Screen operation ................................................4-5
Volkswagen Data Interface with SWC & Factory Display Retention 2015
• Provides accessory power
• Retains R.A.P. (retained accessory power)
• Designed for non-amplified models, or amplified models
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains balance and fade
• Retains most of the vehicle information that was displayed on the
factory radio *
• Micro “B” USB updatable
* Attention!
The aftermarket radios backup camera input will be used to display the vehicle settings. If the radio doesn’t have a backup camera
Input, then there will be no visualization of the vehicle settings. An externally mounted screen could be substituted in this situation.
APPLICATIONS
VOLKSWAGEN
Beetle 2015
Caddy 2015
Jetta 2015
Sharan 2015
T-6 2015
Tiguan 2015
• AX-VW903 interface
• ASWC-1 interface
• AX-VW903 harness
• ASWC-1 harness
• Female 3.5mm connector with stripped leads
2
CONNECTIONS TO BE MADE
From the aftermarket radio to the AX-VW903 harness:
• Connect the wire to the ground wire.Black
• Connect the Yellow wire to the battery wire.
• Connect the wire to the accessory wire.Red
• If the aftermarket radio has an illumination wire, connect the wire to it.Orange
• Connect the unlabeled wire to the power antenna wire.Blue
• Connect the wire labeled “Power Antenna” to the power antenna wire located at the Blue
antenna adapter (sold separately).
• Connect the Brown wire to the mute wire.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the wire to the VSS/speed sense wire.Blue/Pink
• Connect the wire to the reverse wire.Green/Purple
• Connect the wire to the parking brake wire.Light Green
From the aftermarket radio to the ASWC-1 harness:
This harness is only to be used if the vehicle is equipped with steering wheel controls or a backup camera.
• Connect the wire to the accessory wire.Red
• For the radios listed below, connect the
female 3.5mm connector with stripped leads
, to
the
male 3.5mm SWC jack from the ASWC-1 harness. Any remaining wires tape off and disregard
:
• Connect the steering wheel control wire, normally Eclipse: Brown Brown/, to the
White wire of the connector. Then connect the remaining steering wheel control wire,
normally , to the wire of the connector.Brown/White Brown
• Connect the steering wheel control Key 1 wire (Gray) to the wire.Metra OE: Brown
• Kenwood or select JVC with a steering wheel control wire: Blue/Yellow Connect the
wire to the wire.Brown
• XITE:
Connect the steering wheel control SWC-2 wire from the radio to the Brown wire
.
•
Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AX-SWC-PARROT (sold
separately), and then connect the 4-pin connector from the AX-SWC-PARROT into the radio
.
Note:
The radio must be updated to rev. 2.1.4 or higher software.
•
Universal “2 or 3 wire” radio:
Connect the steering wheel control wire, referred to as
Key-A or SWC-1, to the
Brown
wire of the connector. Then connect the remaining
steering wheel control wire, referred to as Key-B or SWC-2, to the
Brown/White
wire of
the connector. If the radio comes with a third wire for ground, disregard this wire.
Note:
After the interface has been programmed to the vehicle, refer to the manual
provided with the radio for assigning the SWC buttons. Contact the radio manufacturer
for more information.
• For all other radios: Connect the 3.5mm jack from the ASWC-1 harness, into the jack on the
aftermarket radio designated for an external steering wheel control interface. Please refer to
the aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.
• Connect the Yellow male RCA jack labeled “To Reverse Camera Input (Radio)”, to the backup
camera input.
Note:
The aftermarket radios backup camera input will be used to display the vehicle
settings. If the radio doesn’t have a backup camera Input, then there will be no visualization
of the vehicle settings. An externally mounted screen could be substituted in this situation.
• If installing an aftermarket backup camera, connect the Yellow female RCA jack labeled “To
Reverse Camera”, to the camera.
3
REV. 5/11/2018 INSTAX-VW903
With the key in the off position:
• Connect the AX-VW903 harness to the AX-VW903 interface, and then to the wiring harness in
the vehicle.
• Connect the ASWC-1 harness to the ASWC-1 interface, and then to the AX-VW903 interface.
INSTALLING THE AX-VW903 INTERFACE
PROGRAMMING THE ASWC-1 INTERFACE
PROGRAMMING THE ASWC-1
INTERFACE
(CONT.)
L.E.D. feedback
The (18) L.E.D. flashes represent what brand radio the ASWC-1 believes it is connected Red
to. Each flash represents a different radio manufacturer. For example, if you are installing
a JVC radio, the
ASWC-1
will flash (5) times. Following is a legend that dictates which
manufacturer corresponds to which flash.
L.E.D. feedback legend
* Note:
If the ASWC-1 flashes (7) times, and you do not have an Alpine radio connected Red
to it, that means the ASWC-1 does not detect a radio connected it. Verify that the 3.5mm
jack is connected to the correct steering wheel jack/wire in the radio.
** Note:
Part number AX-SWC-PARROT is required (sold separately). Also, the Parrot radio
must be updated to rev. 2.1.4 or higher through www.parrot.com.
† Note:
If you have a Clarion radio and the steering wheel controls do not work, change the radio
type to the other Clarion radio type; same for Eclipse. The following section explains how to do this
.
‡ Note:
If you have a Kenwood radio and the L.E.D. feedback comes back as showing as a JVC
radio, change the radio type to a Kenwood. The following section explains how to do this.
1 flash - Eclipse (Type 1) †
2 flashes - Kenwood ‡
3 flashes - Clarion (Type 1) †
4 flashes - Sony / Dual
5 flashes - JVC
6
flashes -
Pioneer / Jensen
7 flashes - Alpine *
8 flashes - Visteon
9 flashes - Valor
10 flashes - Clarion (Type 2) †
11 flashes - Metra OE
12 flashes - Eclipse (Type 2) †
13 flashes - LG
14 flashes - Parrot **
15 flashes - XITE
16 flashes - Philips
17 flashes - TBD
18 flashes - JBL
• Press and hold the Volume-Up button on the steering wheel.
• Turn the ignition on, the L.E.D. in the ASWC-1 interface will start flashing rapidly, which
means the ASWC-1 is looking for the vehicle and the radio.
If the L.E.D. did not start flashing rapidly, press the reset button for 3 seconds, while Note:
still holding the Volume-Up button.
• After a few seconds the L.E.D. should stop flashing rapidly, and then go out for
approximately 2 seconds.
• After approximately 2 seconds there will be a series of 7 flashes, some short, and Green
some long. The long flashes represent the wires that are connected to the ASWC-1. The 3rd,
4th, 5th, and 6th flashes should be longer.
Knowing this will help to troubleshoot, if need be.Tip:
• The L.E.D. will pause for another 2 seconds, and then flash up to 18 times depending on Red
which radio is connected to the ASWC-1. Refer to the L.E.D. feedback section for information.
• This is the end of the auto detection stage. Release from holding the Volume-Up button. If
the ASWC-1 detected the vehicle and the radio successfully, the L.E.D. will light up solid.
• Test the steering wheel controls for proper operation. Refer to the ASWC-1 instructions online
at axxessinterfaces.com for customizing the buttons, if so desired.
