Seite 1/4
AX-MAZBT
I N S TA L L AT I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 8/20/20 INSTAX-MAZBT
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
INTERFACE FEATURES
INTERFACE COMPONENTS
TABLE OF CONTENTS
Installation .............................................................2
App Instructions ..................................................2-3
Mazda Bluetooth Capable Vehicle Customization
2014-Up
APPLICATIONS
Allows retention and
adjustment of the factory
personalization menu
Adjust the personalization
menu through a Bluetooth
application
Smartphone application
offering full control from
either an Android or Apple
mobile device
Plug & play solution, no wiring
required
Mazda
CX-3 2016-Up
CX-5 2017-Up
Mazda3 2014-Up
Mazda6 2016-Up
MX-5 Miata 2016-Up
† Mazda-Connect Infotainment system with a 7-inch touchscreen
• AX-MAZBT interface
• AX-MAZBT harness
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
2
1. Download and install the AX-CUSTOM-BT app from the mobile devices app store.
2. Start the vehicle.
3. Customization Settings Open the app and wait for the menu to appear. If Not Connected
appears instead, first press the right button in the top right corner of the screen, then press
the left button. This will take you back to Customization Settings. The pairing process will
begin at this point.
4. Once paired, will be displayed in the screen. From this point on you can make Settings
changes to the vehicle as desired, as the long as the vehicle is running. (Figure A)
Screenshot shown for illustration Note:
only. Actual options available vary per
vehicle and trim level.
Continued on the next page
INSTALLATION APP INSTRUCTIONS
Connect the AX-MAZBT harness to the AX-MAZBT interface.
Connect the AX-MAZBT harness to the 18-pin connector located at the radio location.
(Figure A)
3
REV. 8/20/2020 INSTAX-MAZBT
Manage Vehicles (Figure B)
Select by pressing the button in the top right of the screen.Manage Vehicles
Pressing either the Add Vehicle Edit or (pencil icon) button will open the Configure Vehicle
menu. (Figure B)
Configure Vehicle (Figure C)
The name of the vehicle can be changed by pressing the text field.
The app can automatically detect the interface installed in the vehicle by pressing the Search
button (magnifying glass).
The Make Model and fields will open a drop down list for the user to select the make and
model of the vehicle that the interface is installed in.
Press the button to store the changes.Save
APP INSTRUCTIONS (CONT.)
(Figure B)
(Figure C)
