CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AX-FT902
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 5/11/18 INSTAX-FT902
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.) • Zip ties
TABLE OF CONTENTS
Connections to be made ....................................2-3
Installing the AX-FT902 interface .........................3
Programming the ASWC-1 interface ................. 3-4
Screen operation ................................................4-6
Fiat 500X (with U-Connect) Data Interface with SWC & Factory Display Retention 2015
Provides accessory power
Designed for non-amplified models
Provides NAV outputs (parking brake, reverse, speed sense)
Retains audio controls on the steering wheel
Retains parking sensor chimes
Retains balance and fade
Retains most of the vehicle settings that was displayed on the
factory radio *
Micro “B” USB updatable
AX-FT902 interface
ASWC-1 interface
AX-FT902 harness
ASWC-1 harness
Female 3.5mm connector with stripped leads
Chime Speaker
* Attention!
The aftermarket radios backup camera input will be used to display the vehicle settings. If the radio doesn’t have a backup camera
Input, then there will be no visualization of the vehicle settings. An externally mounted screen could be substituted in this situation.
2
CONNECTIONS TO BE MADE
From the aftermarket radio to the AX-FT902 harness:
Connect the wire to the ground wire.Black
Connect the Yellow wire to the battery wire.
Connect the wire to the accessory wire.Red
If the aftermarket radio has an illumination wire, connect the wire to it.Orange
Connect the wire to the power antenna turn-on wire.Blue
Connect the wire to the left front positive speaker wire.White
Connect the wire to the left front negative speaker wire.White/Black
Connect the wire to the right front positive speaker wire.Gray
Connect the Gray/Black wire to the right front negative speaker wire.
Connect the wire to the left rear positive speaker wire.Green
Connect the wire to the left rear negative speaker wire.Green/Black
Connect the wire to the right rear positive speaker wire.Purple
Connect the wire to the right rear negative speaker wire.Purple/Black
The following (3) wires are only for multimedia/navigation radios that require these wires.
Connect the wire to the VSS/speed sense wire.Blue/Pink
Connect the wire to the reverse wire.Green/Purple
Connect the wire to the parking brake wire.Light Green
From the aftermarket radio to the ASWC-1 harness:
This harness is only to be used if the vehicle is equipped with steering wheel controls or a backup camera.
Connect the wire to the accessory wire.Red
For the radios listed below, connect the
female 3.5mm connector with stripped leads
, to
the
male 3.5mm SWC jack from the ASWC-1 harness. Any remaining wires tape off and disregard
:
Connect the steering wheel control wire, normally Eclipse: Brown Brown/, to the
White wire of the connector. Then connect the remaining steering wheel control wire,
normally , to the wire of the connector.Brown/White Brown
Connect the steering wheel control Key 1 wire (Gray) to the wire.Metra OE: Brown
Kenwood or select JVC with a steering wheel control wire: Blue/Yellow Connect the
wire to the wire.Brown
XITE:
Connect the steering wheel control SWC-2 wire from the radio to the Brown wire
.
Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AX-SWC-PARROT (sold
separately), and then connect the 4-pin connector from the AX-SWC-PARROT into the radio
.
Note:
The radio must be updated to rev. 2.1.4 or higher software.
Universal “2 or 3 wire” radio:
Connect the steering wheel control wire, referred to as
Key-A or SWC-1, to the
Brown
wire of the connector. Then connect the remaining
steering wheel control wire, referred to as Key-B or SWC-2, to the
Brown/White
wire of
the connector. If the radio comes with a third wire for ground, disregard this wire.
Note:
After the interface has been programmed to the vehicle, refer to the manual
provided with the radio for assigning the SWC buttons. Contact the radio manufacturer
for more information.
Continued on the next page
3
REV. 5/11/2018 INSTAX-FT902
For all other radios: Connect the 3.5mm jack from the ASWC-1 harness, into the jack on the
aftermarket radio designated for an external steering wheel control interface. Please refer to
the aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.
Connect the Yellow male RCA jack labeled “To Reverse Camera Input (Radio)”, to the backup
camera input.
Note:
The aftermarket radios backup camera input will be used to display the vehicle
settings. If the radio doesn’t have a backup camera Input, then there will be no visualization
of the vehicle settings. An externally mounted screen could be substituted in this situation.
If installing an aftermarket backup camera, connect the Yellow female RCA jack labeled “To
Reverse Camera”, to the camera.
With the key in the off position:
Connect the AX-FT902 harness to the AX-FT902 interface, and then to the wiring harness in the vehicle.
Zip tie the chime speaker under the dash to a location where it will be heard clearly by the
driver, then route the harness to the radio location.
Connect the chime speaker to the AX-FT902 Interface.
Connect the ASWC-1 harness to the ASWC-1 interface, and then to the AX-FT902 interface.
Press and hold the Volume-Up button on the steering wheel.
Turn the ignition on, the L.E.D. in the ASWC-1 interface will start flashing rapidly, which
means the ASWC-1 is looking for the vehicle and the radio.
Note:
If the L.E.D. did not start flashing rapidly, press the reset button for 3 seconds, while
still holding the Volume-Up button.
After a few seconds the L.E.D. should stop flashing rapidly, and then go out for
approximately 2 seconds.
After approximately 2 seconds there will be a series of 7 Green flashes, some short, and
some long. The long flashes represent the wires that are connected to the ASWC-1. The 3rd,
4th, 5th, and 6th flashes should be longer.
Tip:
Knowing this will help to troubleshoot, if need be.
The L.E.D. will pause for another 2 seconds, and then flash up to 18 times depending on Red
which radio is connected to the ASWC-1. Refer to the L.E.D. feedback section for information.
This is the end of the auto detection stage. Release from holding the Volume-Up button.
If the ASWC-1 detected the vehicle and the radio successfully, the L.E.D. will light up solid.
Test the steering wheel controls for proper operation. Refer to the ASWC-1 instructions online
at axxessinterfaces.com for customizing the buttons, if so desired.
INSTALLING THE AX-FT902 INTERFACE
INSTALLING THE AX-FT902 INTERFACE
PROGRAMMING THE ASWC-1 INTERFACE
Continued on the next page
