AX-ALOC10
INSTALL ATION INSTRUCTI O N S
REV. 4/27/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
2 Channel, Fixed Line-Output Converter
The AX-ALOC10 is designed to convert speaker level audio to line level
audio. This allows for the installation of line level products such as
amplifiers, EQs and crossovers on systems that do not have RCA line
level outputs.
Features:
30 Watts Maximum Input, 6:1 Step Down with Fixed Outputs, Gold
Flashed RCAs, Attractive & Durable Enclosure.
AX-ALOC10
INSTALL ATION INSTRUCTI O N S
REV. 4/27/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com
The AX-ALOC10 should be installed on a stereo’s speaker output wires or the output wires
on an OEM amplifier of up to 30 watts per channel. These wires can be found behind the
stereo in the dash, on the outside of an OEM amplifier, or on the input terminals on the
OEM speakers. This device is most commonly installed in the trunk when a subwoofer
system is being added to the OEM stereo system. Please refer to the wiring diagram for
the input connection details.
Wire Color & Function: The audio and power input wire colors are an EIA standard for car
stereo applications as follows.
Note: Be sure that all audio input connections are polarized or in phase with each other.
That is, the positive output wires from the audio source need to be connected to the
corresponding positive input wires of the AX-ALOC10. The same goes for the negative
audio wires. Failure to do this will result in poor bass response and low quality audio.
Installation Instructions
INPUT HARNESS
White LEFT Front (+) Input
White/Black LEFT Front (-) Input
Gray RIGHT Front (+) Input
Gray/Black RIGHT Front (-) Input
Black Reference Ground (-)
(Reference ground optional if noise is present)
