Installation Instructions for AX-ADXSVI-GM2

REV. 1/16/2014 INSTAX-ADXSVI-GM2

(continued on next page)

AX-ADXSVI-GM2

WIRING THE AX-ADXSVI-GM2

• Connect the Yellowwire to the radio’s 12 volt battery or memory wire.        

• Connect the wire to the radio’s ground wire. Black     

• Connect the wire to the ignition wire of the aftermarket radio. Red        

• Connect the wire to the illumination wire of the aftermarket radio. If the Orange           

aftermarket radio has no illumination wire,        tape off the Orange wire.

• The wire will not be used in this application.Orange/White        Tape     up or cap off this

wire and disregard it.  

• Connect the wire to the antenna turn on wire of the aftermarket radio. Blue          

• Connect the wire to the left front positive speaker output of the aftermarket radio. White           

• Connect the wire to the left front negative speaker output of the White/Black          

aftermarket radio.

• Connect the wire to the right front positive speaker output of the Gray          

aftermarket radio.

• Connect the wire to the right front negative speaker output of the Gray/Black          

aftermarket radio.

• Connect the wire to the radio’s left rear positive speaker output. Green        

• Connect the wire to the radio’s left rear negative speaker output. Green/Black        

• Connect the wire to the radio’s right rear positive speaker output. Purple        

• Connect the wire to the radio’s right rear negative speaker output. Purple/Black        

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G5 2007-2008

G6(5th digit of VIN must be a J, K, or L) 2009

G6 2010

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2006-2009

APPLICATIONS

KIT FEATURES

• Provides accessory (12 volt 10 amp)    

• Retains R.A.P.   (retained accessory power)

• Used innon-amplified systems or when replacing amplified system      

• Provides outputs (parking brake, reverse, NAV     and V.S.S.)

• Prewired ASWC-1 harness included (ASWC-1 sold separately)     

• High level speaker input  

• USB updatable

Note:

1)This harness must be used in conjunction with the AX-ADXSVI        

2)All chimes will be lost when using this harness       

AX-ADXSVI-GM2

The following wires are for the aftermarket radios that have navigation built in.           

• Connect the wire to the parking brake wire of the aftermarket navigation  Light Green          

radio (if applicable). 

• Connect the wire to the Blue/Pink   VSS or speed sense wire of the aftermarket       

navigation radio (if applicable).  

• Connect the wire to the reverse wire of the aftermarket navigation radio Green/Purple          

(if applicable).

• Cycle the key,          by turning the ignition on for 30 seconds. Then off and on again to test      

the radio.

AS )WC-1 (if installing

After the XSVI is initialized,              plug in the ASWC-1 into the 12-pin harness of the AX-ADXSVI-

GM2 and refer to the ASWC-1 instructions.     

K PNOWLEDGE IS OWER

Enhance your inst allation and fabrication skills by

enrolling in the most cognized and spected re re

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take steps re

toward a better t omorrow.

Metra recommends MECP

certiﬁed technicians

IMPORTANT WARNING

Thisproductincludesinstructionsforinstallationwhichmustbecarefullyfollowed.The

instructionsarewordedinsuchamannertoassumethattheinstalleriscapableof

completingthesetypeofelectronicinstallations.Ifyouareunclearastowhatyouare

instructedtodoorbelievethatyoudonotunderstandtheinstructionssoastoproperly

andsafelycompletetheinstallationyou should consult a technician who does have this

knowledge and understanding.

Failure to follow these instructions carefully and to install the interface as described

could cause harm to the vehicle or to safety systems on the vehicle. Interference with

certain safety systems could cause harm to persons as well. If you have any questions

in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
