CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AX-AB-TY3
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com Ā© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 11/8/18 INSTAX-AB-TY3
TOOLS REQUIRED
ā€¢ Crimping tool and connectors, or solder gun,
solder, and heat shrink
ā€¢ Tape ā€¢ Wire cutter ā€¢ Zip ties
TABLE OF CONTENTS
Ampliļ¬er Location .................................................2
Connections ............................................................2
Toyota Tundra (Access Cab)
Ampliļ¬er Bypass Harness 2005-2006
ā€¢ Ampliļ¬er bypass harness
ā€¢ Vehicle-speciļ¬c harness to bypass the factory ampliļ¬er
ā€¢ Allows loose wires to wire to an aftermarket ampliļ¬er
ā€¢ Saves the installer unnecessary labor and wire
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle speciļ¬c applications
2
CONNECTIONS
Gray Front Right Speaker +
Gray/Black Front Right Speaker -
White Front Left Speaker +
White/Black Front Left Speaker -
Green Rear Left Speaker +
Green/Black Rear Left Speaker -
Purple/White Rear Right Speaker +
Purple/Black Rear Right Speaker -
Ampliļ¬er Location: Under center console
3
REV. 11/8/2018 INSTAX-AB-TY3
