Seite 1/8
Owner’s Manual
DisplayPort v1.2 to HDMI
Multi-Stream Transport (MST)
Hub
Models: B156-002-HDMI, B156-004-HD
1111 W. 35th Street, Chicago, IL 60609 • www.tripplite.com/support
Copyright © 2015 Tripp Lite. All rights reserved.
Product Features 2
System Requirements 2
Package Contents 3
Mounting Instructions 3
Installation Instructions 4
Troubleshooting 5
Warranty & Product Registration 7
15-04-233-9333F6.indd 1 4/16/2015 2:56:54 PM
2
Product Features
System Requirements
• Display the same image on both monitors, extend the desktop across
them, or display in video wall mode where both monitors are combined
to display as one, enlarged monitor.*
• DisplayPort v1.2 compliant*
• Supports 4K x 2K Ultra High Definition (UHD) video resolutions up to
3840 x 2160 (24 and 30 Hz) – see System Requirements
• Supports up to 48-bit Deep Color (16 bits per channel)
• Supports DTS-HD, Dolby True HD and 7.1 channel surround sound audio
• Supports HDCP, EDID and DDC
• Locate a monitor up to 35 ft. from the hub
• Comes with mounting hardware that allows the unit to be
wall-mounted, rackmounted or pole mounted
• Compliant with the Federal Trade Agreements Act (TAA) for GSA
Schedule purchases
* Backward compatible with most DisplayPort 1.1a equipment running current
graphics drivers, with the feature set being limited to that of your equipment
(e.g. you may be limited to displaying in Clone / Mirror mode only). Compatibility
with older graphics cards is not guaranteed.
• A computer with a DisplayPort v1.2 compatible Graphics Card.
Backward compatible with most DisplayPort 1.1a equipment running
current graphics drivers, with the feature set being limited to that of
your equipment (e.g. you may be limited to displaying in Clone / Mirror
mode only). Compatibility with older graphics cards is not guaranteed.
• Maximum supported video resolutions and number of monitors will be
dependent upon your graphics card. Check the specifications of your
graphics card to determine its capabilities.
•
The B156-002-HDMI will allow for video resolutions up to 3840 x 2160
(4K) to be displayed on each monitor, whereas the B156-004-HD only
supports video resolutions up to 1920 x 1080 (1080p) on each port. When
using the B156-004-HD to display all four monitors in video wall mode,
expanded video resolutions are supported, such as 3840 x 2160 in a 2X2
monitor configuration, or 7680 x 1080 in a 4X1 monitor configuration.
• A monitor with a HDMI port.
15-04-233-9333F6.indd 2 4/16/2015 2:56:54 PM
3
Package Contents
• B156-002-HDMI or B156-004-HD
• Mounting Hardware
• External Power Supply (Input: 100-240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
• Owner’s Manual
Optional Accessories:
• P568-Series High Speed HDMI Cables
• P580-Series DisplayPort Cables
• P583-Series Mini DisplayPort to DisplayPort Cables
Mounting Instructions
The B156-002-HDMI and B156-004-HD come with mounting hardware
that allow them to be mounted in a variety of ways. The following images
show the different ways the included mounting brackets can be attached
for different mounting methods.
Note: The images below show a B140-1A0, but the mounting hardware installation
is the same for the B156-002-HDMI and B156-004-HD.
Wall-mount
19” Rackmount Pole Mount
15-04-233-9333F6.indd 3 4/16/2015 2:56:55 PM
