Seite 1/32
DVI Splitter with Audio
and Signal Booster,
1080p 60 Hz
Models: B116-002A, B116-002A-INT
and B116-004A
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
Español 9 • Français 17 • Deutsch 25
Owner’s Manual
2
• B116-002A, B116-002A-INT or B116-004A Splitter
• External Power Supply with 4.5 ft. Cord
(Input: 100-240V, 50/60 Hz, 0.35A; Output: 5V 2A)
• (4x) International Plug Adapters (B116-002A-INT only)
• Mounting Hardware
• Owner’s Manual
Optional Accessories
Product Features
Package Contents
• Delivers a single-link DVI-D video + audio signal to 2 (B116-002A and
B116-002A-INT) or 4 (B116-004A) sets of DVI monitors and speakers
• Cascade up to 3 levels of splitters to expand the number of connected displays and
speakers to 64
• Built-in signal booster increases the distance between the splitter and connected
displays past the standard 16 ft. limitation
• Supports computer video resolutions up to 1920 x 1200 and HD resolutions up to
1080p
• International plug adapters allow connection to outlets in North America, U.K.,
Europe and Australia
• Compatible with HDCP, EDID and DDC standards
• Plug-and-play operation with no software required for easy, immediate installation
• Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
• B120-000* Dual-Link** DVI Extender
• P312-Series 3.5 mm Stereo Audio Cables
• P560-Series Dual-Link** DVI-D with 3.5 mm Audio Cable
• P561-Series Single-Link DVI-D Cables
*A B120-000 extender will only extend the DVI video signal, not the 3.5 mm audio.
** The B116-002A, B116-002A-INT and B116-004A splitters only support single-link DVI-D signals.
Dual-link DVI cables and extenders can be used, but they will only transmit a single-link DVI-D signal.
3
The B116-002A, B116-002A-INT and B116-004A include mounting hardware that
allows them to be mounted in a variety of ways. The following images show the different
ways the included mounting brackets can be attached for different mounting methods.
19” Rack Mount
Wall Mount
Mounting Instructions
Pole Mount
