Seite 1/12
Video Splitter
(2 and 4 Port)
Models: B114-002-R, B114-004-R
Note: Follow these installation and operating procedures to ensure
correct performance and to prevent damage to this unit or to its connected devices.
Introduction 2
Package Contents 2
Product Features 2
Installation 2
Specifications 3
Warranty & Product Registration 3
Español 5
Français 9
Owner's Manual
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
All trademarks are the property of their respective owners.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
2
Stand-Alone Installation:
1. Connect the PC's video output port to the Video Splitter's “Video In” port using an HDDB15
Male/Female Monitor Extension Cable (such as Tripp Lite’s P500-Series Cables).
2. Connect the Video Splitter's “Video Out” ports to the input of your monitors either by using the
existing cable on the monitor or by using an HDDB15 Male/Male Monitor Cable
(such as Tripp Lite’s P502-Series Cables).
3. Connect the provided power supply to the Video Splitter and turn on the unit. Your Video
Splitter is ready to go.
WARNING!
Use ONLY the 9V DC external power supply included with the unit.
The Video Splitter is a signal booster and splitter that takes video input from a single source
and directs it to multiple video outputs for monitors using analog signals. It extends the distance
a signal is sent up to 210 ft.
• B114-002-R or B114-004-R
• External Power Supply (Input: 100-240V, 50/60Hz, 0.4A Output: 9V 1A)
• Owner’s Manual
Introduction
Package Contents
Product Features
Installation
• One video input to multiple video outputs
• Transmission distance of up to 210 feet
• Suitable for VGA/SVGA/XGA/UXGA and Multisync monitors
• Cascade up to 3 levels of splitters to increase the number of outputs
• Supports 350 MHz bandwidth
IMPORTANT NOTE: This unit is not designed for CGA, EGA or MONOCHROME type
monitors or any monitor using a digital video signal.
3
Power Supply DC 9V 1A
Maximum Cable Length 210 feet
Signal Type VGA/SVGA/XGA/UXGA/Multisync
Warranty & Product Registration
Specifications
Installation
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three
(3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or
replacing (at its sole option) any such defective products. To obtain service under this warranty, you must
obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service
center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation
charges prepaid and must be accompanied by a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to equipment which has been damaged by
accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit
limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not
apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED
OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits
or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes,
claims by third parties, or otherwise.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Product Registration
Visit tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Multiple Unit Installation:
1. Connect the “Video Out” port from the first Video Splitter to the “Video In” port of the next
unit in the chain. Use a standard VGA HDDB15 Male/Female Cable (such as Tripp Lite’s
P500-Series Cables).
2. Connect the power supplies to the Video Splitters and turn the power switch on.
3. Repeat steps 1 and 2 to connect up to three levels of Video Splitters to the chain, with the
initial splitter being level one.
