Owner’s Manual
UHD 4Kx2K HDMI Splitters
Models: B118-002-UHD, B118-002-UHDINT,
B118-004-UHD, B118-008-UHD
1111 W. 35th Street, Chicago, IL 60609 • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Product Features 2
Package Contents 3
Installation 4
Troubleshooting 6
Warranty & Product Registration 7
Español 9
Français 17
Pусский 25
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
20-09-261-9336A7-Book.indb 1
20-09-261-9336A7-Book.indb 1
20-09-261-9336A7-Book.indb 1
20-09-261-9336A7-Book.indb 1
20-09-261-9336A7-Book.indb 1 7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
2
Product Features
• Simultaneously transmit video and audio from an HDMI source to
multiple HDMI monitors
• Supports UHD 4K x 2K video resolutions up to 3840 x 2160
(24 Hz and 30 Hz) and 3D
• Supports 36-bit Deep Color (12 bits per channel)
• Supports DTS-HD, Dolby® TrueHD, Dolby Digital Plus™ and LPCM
7.1 Channel Surround Sound audio
• Supports video amplifier bandwidth of 340 MHz / 3.4 Gbps per channel
(10.2 Gbps total)
• HDCP and EDID compatible
• Plug and play; no software or drivers required
• The B118-002-UHD features a built-in cable to connect to the source
• The B118-002-UHDINT and B118-008-UHD include an international
power supply with compatible North American, UK, European and
Australian plug adapters
• Supports lip sync pass-through
• Supports xvYCC and x.vColor
• Supports the use of DVI sources and displays with an optional DVI to
HDMI adapter (sold separately)
•
Supports a maximum distance of 16.4 ft. (5 m) from source to splitter,
and 23 ft. (7 m) from splitter to display, for a total of up to 39.4 ft. (12 m)
• Cascade up to 3 levels of splitters to increase up to 512 connected
monitors.
20-09-261-9336A7-Book.indb 2
20-09-261-9336A7-Book.indb 2
20-09-261-9336A7-Book.indb 2
20-09-261-9336A7-Book.indb 2
20-09-261-9336A7-Book.indb 2 7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
3
Package Contents
• UHD 4K x 2K HDMI Splitter
• External Power Supply
• B118-002-UHD (Input: 100-240V, 50/60 Hz, 0.2A; Output: 5V 1A)
•
B118-002-UHDINT (Input: 100-240V, 50/60 Hz, 0.2A; Output: 5V 1A)*
• B118-004-UHD (Input: 100-240V, 50/60 Hz, 0.35A; Output: 5V 2A)
• B118-008-UHD (Input: 100-240V, 50/60 Hz, 0.6A; Output: 5V 3A)*
• Mounting Hardware (B118-008-UHD only)
• Owner’s Manual
* Includes NEMA 1-15P (North America), CEE 7/16 Schuko (Europe), BS 1363 (UK)
and AS/NZS 3112 (Australia) plugs.
Optional Accessories:
• P130-000 HDMI to DVI Adapter
• P566-Series HDMI to DVI Adapter Cables**
• P568-Series High Speed HDMI Cables
**When using an HDMI to DVI adapter cable, only the video signal will be transmitted
to the DVI monitor and video resolutions will be limited to those supported by the
adapter.
20-09-261-9336A7-Book.indb 3
20-09-261-9336A7-Book.indb 3
20-09-261-9336A7-Book.indb 3
20-09-261-9336A7-Book.indb 320-09-261-9336A7-Book.indb 3 7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM
7/22/2021 11:32:56 AM7/22/2021 11:32:56 AM
