Seite 1/16
OPAL P ro
Outdoor dual technology motion detector
Firmware version opal_pro_en 03/21 2.00
SATEL sp. z o.o. ul. Budowlanych 66 - POLAND • • 80 298 Gdańsk •
tel. +48 58 320 94 00
www.satel.eu
WARNING
The device should be installed by qualied personnel.
Read carefully this manual before proceeding to installation.
Changes, modications or repairs not authorized by the manufacturer shall void your rights
under the warranty.
SATEL aims to continually improve the quality of its products, which may result in changes in
their technical specications and software. Current information about the changes being
introduced is available on our website.
Please visit us:
https://support.satel.eu
The declaration of conformity may be consulted at www.satel.eu/ce
The following symbols may be used in this manual:
- note;
- caution.
CONTENTS
1. Features ........................................................................................................................... 2
2. Description ........................................................................................................................ 2
Active IR anti-mask ........................................................................................................... 2
Dusk sensor ...................................................................................................................... 3
Supervision features ......................................................................................................... 3
LED indicators .................................................................................................................. 3
Remote conguration mode enable / disable .................................................................... 4
3. Electronics module ........................................................................................................... 4
4. Installation 5........................................................................................................................
Wall mounting ................................................................................................................... 8
Angle bracket mounting .................................................................................................... 8
Ball bracket mounting ....................................................................................................... 9
Connecting the additional tamper switch ........................................................................ 11
5. Conguring the detector ................................................................................................. 11
Starting conguration mode ............................................................................................ 11
Signaling in the conguration mode ................................................................................ 11
Conguring by means of the detector buttons ................................................................ 12
Conguring by means of OPT-1 keyfob .......................................................................... 12
Ending conguration mode ............................................................................................. 12
6. Anti-mask delay .............................................................................................................. 12
7. Walk test ......................................................................................................................... 13
Separate testing of sensors ............................................................................................ 13
8. Specications .................................................................................................................13
