B10 Subwoofer

Owner’s Manual

2B10 Subwoofer

Owner’s Manual

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.

A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the

provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles and the point where they exit from

the apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod, bracket or table speciﬁed by the manufacturer or sold with the apparatus.

When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power

supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, or the apparatus has been exposed to rain or

moisture, does not operate normally or has been dropped.

15. Do not expose this apparatus to dripping or splashing and ensure that no objects ﬁlled with liquids, such as vases, are placed on the apparatus.

16. The mains plug is used as disconnect device, the disconnect device shall remain readily operable.

17. WARNING: Apparatus shall be connected to a MAINS socket outlet with a protective earthing connection.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ATTENTION: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR.

The lightning ﬂash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated

“dangerous voltage” within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to

persons.

Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts

inside. Refer servicing to qualiﬁed personnel.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature accompanying the product.

WARNING: To reduce the risk of ﬁre or electric shock, do not expose this apparatus to rain or moisture.

Operating Temperature 35˚C.

B10 Subwoofer

Owner’s Manual

ABOUT THE REVEL® CONCERTA 2™

B10 SUBWOOFER

Thank you for purchasing the Revel Concerta 2 B10, a high-performance

powered subwoofer that perfectly augments Revel Concerta 2 Series

loudspeakers in stereo music or home theater entertainment systems.

The B10’s adjustable controls allow you to optimize the subwoofer’s

performance in any system and listening room.

Featuring a 10" (254mm) woofer with 1-1/2" (26mm) peak-to-peak

excursion and powered by a 800-watt ampliﬁer, the B10 subwoofer

reproduces deep, realistic bass with very low distortion, even at the

lowest frequencies and high output levels.

Combining superior form and function, the B10’s proprietary woofer is

constructed with an polycellulose ﬁber diaphragm for great strength at

high output levels. The spider incorporates a superior-strength Corex/

cotton blend with optimized geometry for increased linearity. The motor

includes a large ceramic-magnet motor system. A 2.6" (50.8mm) copper

voice coil is wound on a Kapton® bobbin for impressive power handling

and freedom from compression. The vented center pole facilitates

heat dissipation, allowing more efﬁcient high-power handling and low

compression.

The B10 cabinet consists of medium-density ﬁberboard (MDF) walls and

extensive internal bracing to reduce cabinet-induced colorations. Rubber

padded feet are attached to the bottom of the cabinet for optimal

stability, accommodating installations on any ﬂoor surface.

Since 1996, the Revel brand has been at the forefront of loudspeaker

design. Backed by Harman International’s extensive research and design

facilities, Revel Concerta 2 Series speakers beneﬁt from cutting-edge

development tools, such as:

• A multichannel listening lab allows for double-blind listening tests.

• A laser interferometer enables detailed driver and cabinet analysis.

• Multiple large anechoic chambers provide for precise tests and

measurements.

• Finite-element analysis allows for advanced loudspeaker modeling.

• A stereo lithography apparatus aids in achieving tight tolerances.

Adding to the proud lineage of Revel Ultima™ and Performa™ Series

loudspeakers, the subwoofer further substantiates the Revel reputation

for high-quality, high-performance loudspeakers and subwoofers.

B10 HIGHLIGHTS

• High-output capability with low distortion

• Proprietary 10" (254mm) anodized-aluminum diaphragm woofer

• Built-in 800W RMS ampliﬁer

• Line-level RCA inputs

• Advanced woofer motor structure

• Large voice coil for wide dynamic range without compression

• Phase switch

• Low-pass frequency control

• Parametric room equalization controls

• Elegant cabinet design with paint ﬁnishes

SUBWOOFER PLACEMENT

Below 300Hz, loudspeaker and listener locations have a profound impact

on the way sound is reproduced. All rooms have “standing waves,” by

which certain frequencies are emphasized or diminished. Their complex

patterns can combine to introduce tremendous sound coloration at low

frequencies.

The Concerta 2 B10’s Equalization controls can help to compensate for

these effects, but no electronic system alone can fully compensate for

the dramatic effects of room acoustics. Every room has locations where

“nulls” at speciﬁc frequencies occur. These cancellations of the sound

are like “black holes,” which no amount of equalization can ﬁll. The

best results are always achieved through careful placement of both the

loudspeakers and the listening position. Preferable placement can be

determined through the use of computer modeling programs, or by trial-

and-error measurements. For optimal results, ﬁnd the best loudspeaker

and listener locations ﬁrst, then use the B10 Equalization controls for

ﬁne-tune adjustments.

To help determine good locations for the subwoofer(s) and the

listener(s), it is recommended that you make high-resolution in-room

response measurements. Your authorized Revel dealer can make the

appropriate measurements, using suitable equipment to ensure optimal

results.

NOTE: Many sound-measurement devices are not accurate

enough to properly measure low-frequency performance in a

listening room, since room boundaries can often cause modes

(standing waves) with very narrow-band peaks and dips.

Check with your authorized Revel dealer to conﬁrm that your

measurement equipment is suitable for accurate, high-resolution

measurements.
