Olight SRMÍNI II Intimidator Bedienungsanleitung

Olight Taschenlampe SRMÍNI II Intimidator

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Olight SRMÍNI II Intimidator (1 Seiten) in der Kategorie Taschenlampe. Dieser Bedienungsanleitung war für 15 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Seite 1/1
ŸBATTERY CHARGE
Firstly, slide the USB port cover aside, then connect the flashlight to external
USB power supply, the status indicator turn on means charging is in process.
Thank you for purchasing Olight products! Please read this manual
carefully before use.
Within 30 days of purchase Return to retailer from which you purchased :
for repair or replacement.
Within 5 years of purchase Return to Olight for repair or replacement. :
This warranty does not cover normal wear and year,modifications, misuse,
disintegrations,negligence, accidents, improper maintenance, or repair by
anyone other than an Authorized retailer or Olight itself.
NOTE: One of t he f ol lowing o utput mo de s low, med iu m, h ig h, w il l be
memo ri ze d when the l ig ht s hutting off. Th e flashl ig ht wil l no t
memo ri ze the low mod e when the l ig ht is acti vate d to l ow m ode
dir ectly b ef or e it is tur ne d of f. For high mod e, the l ig ht w ill only
memo ri ze high mode f or 1 0 mi nute s when the l ig ht is of f, after 10
minutes th e memori ze d mo de w il l switch t o medi um mod e.
Tec hni cal su pport: te chs upport @ol ightworl d.com
Cu sto mer se rvice : cs@oligh two rld .co m
Website: www.olightworld.com
WARRANTY
SPECIFICATIONS
1,600 lumens / 3 hours
600 lumens / 8 hours
120 lumens / 36 hours
10Hz
3xCree XM-L2 CW
2.8 to 6v
18,000cd
268 meters
3 x 18650 (with protecting circuit board)
Type hard anodized aluminum
IPX8
L 132mm x D 47.5mm / 5.2in x 1.9in
ŸTURN ON/OFF
Quick click the side switch to turn the flashlight on or off. The light will turn to
the last output mode before shutting off.
ŸCHANGE BRIGHTNESS LEVELS
With the light on, press and hold the side switch, the output will cycle through
low, medium, and high brightness levels. Release the side switch when the
desired brightness level is achieved.
ŸLOW MODE
With light off, press and hold the side switch for more than 1 second, the low
mode will be activated.
ŸTURBO MODE
Double-click the side switch to activate turbo mode if the light is in non-
locking state.
ŸSTROBE MODE
When the light is in non-lock state, Triple -click side switch to activate strobe
mode. Click the side switch once to quit strobe mode, press and hold side
switch to turn on the setting of changing brightness level.
ŸLOCK MODE
With the light off, press the side switch and hold for 1 second to activate low
mode, keep holding the switch for one more second, the light will shut off
automatically and lock the side switch. Under lock state, click and release the
switch, the red indicator will last for 2 seconds.
ŸUNLOCK MODE
When the light is off, press and hold side switch for more than 2 seconds, the
switch is enable and activate low mode. User may twist the tail cap anti-
clockwise to turn off the light, tighten the tail cap clockwise to unlock the
light.
ŸSTATUS INDICATOR
There is a multi-purpose status indicator lamp at the upside of the USB
charging port to indicate the battery low voltage or charging state:
Battery low voltage indication: When the battery voltage is less than 3.25V,
the status indicator lamp will flicker in red; when the battery voltage is less
than 3.05V, the status indicator lamp will be a constant red.
Charging state indication: red means under charging; green means fully
charged.
3,200 lumens
Al l per fo rmance claim to A NSI/ NE MA F L1-2009 stand ar d
Made in China
TURBO
HIGH
MED
LOW
STROBE
LED
Operate Voltage
Candela
Beam Distance
Supported Batteries
Material
Water-proof
Impact Resistance
Dimensions
Weight
181g / 6.4oz (excluding batteries)
1.5 meters
SUPPORTED BATTERIES
INSIDE THE BOX
Flashlight, holster, USB cable, user manual (this manual), and other optional
accessories( refer to the label marks outside of box for detail)
3 x 18650 rechargeable lithium batteries with protecting circuit board , the
batteries must have a protruding button on positive pole.
Not e: Tes t s p e rf or me d w it h 3 x18 650 bat te ri e s ( 340 0m Ah , 3. 6v )
OPERATION INSTRUCTION
Ÿ BATTERY INSTALLATION
Before use, install the batteries and notice that the battery positive towards
the flashlight head, then tightly screw the tail- cap as shown below.
WA R NI N G:
CONTACT
Do not mix rechargea bl e a nd non- re char ge able b at teries .
Do not mix batt erie s of d if fere nt ty pes/bra nd s.
Pr operly inst al l t he bat te ries, t he po si ti ve of batte ry to wards the h ead o f
the flash li gh t, thr ee batt er ie s are in sam e dir ecti on.
Th e produ ct o nly support th e batte ries with protr udin g but ton on t he
po si tive a nd with pro tect ing c ir cuit board, r ecommend to use t he batt ery
ce ll cap acit y o f 18650 with 3 00 0m Ah o r abo ve.
Lo w batte ry prote ct io n: if t he batter y voltage dro p down t o 2.7V, the
fl ashl ight w il l n ot tu rn o n, the in di cato r will e mit red color wh en t he swit ch
is pressed.
Us e cau tion for lon g runt imes at h igh lev el and tu rbo a s fla sh li gh t m ay get
hot.
Th re e bat te ri es are para ll el ly c onne cted inside the flashl ight , eit he r 1 o r 2
or 3 bat te ries are abl e t o t ur n t he flash li gh t o n, it is bette r n ot to u se Turbo
wh en u si ng 1 or 2 ba tter ies, i t m ay ca use t o sud de nl y shu t d ow n due t o
batt ery prote ctio n.
Pl ease c hoos e 5V 2.1A U SB po we r supply o r h ighe r rat e power su pply t o
ch arge t he flash lig ht .
S ide switch
Charge indicator /
Low voltage indicator
Micro-USB
Charging Port
Output
