Note: testing done with 3 x 18650 batteries (3.6V, 3400mAh)
Thank you for purchasing the Olight SR52UT
Intimidator flashlight! Please read this manual
carefully before using this product.
SR52UT INTIMIDATOR
EXTENDED-RANGE RECHARGEABLE LED FLASHLIGHT
USER MANUAL
WARRANTY
Within 30 days of purchase: Return to retailer
from which you purchased for repair or replacement.
Within 5 years of purchase: Return to Olight for
repair or replacement.
This warranty does not cover normal wear and tear,
modifications, misuse, disintegrations, negligence,
accidents, improper maintenance, or repair by anyone
other than an Authorized retailer or Olight itself.
Technical Support Inquiries
techsupport@olightworld.com
Customer Service
cs@olightworld.com
Visit www.olightworld.com to see our
complete product line of portable
illumination tools.
INSIDE THE BOX
SR52UT Intimidator, Micro-USB cable, manual,
holster, USB vehicle power adapter,
3X18650(optional)
ON
HOW TO OPERATE
ON/OFF:Click the side switch to turn ON/OFF the
flashlight. The brightness level will return to last output
level (except strobe mode) when the flashlight is turned
on.
CHANGE BRIGHTNESS LEVEL (FIG A)
With the light already on, press and hold the side switch
to cycle through the brightness level from low – medium
– high until the desired brightness level selected by
releasing the side switch.
STROBE (FIG A) Double-click the side switch will
activate the strobe mode. Hold down the side switch for
1 second to quit strobe mode, the flashlight will return
to memorized output level.
LOCKING: (FIG B) When the light is off, press and hold
the side switch, the light will be turned on temporarily two
seconds then shut off automatically. That indicates the side
switch operation has been disabled already for preventing
accidental operation.
UNLOCKING: (FIG B) With the light off, press and
hold the side switch approximately one second to enable
the side switch operation.
CHARGING THE FLASHLIGHT(FIG C)
Push the cover above the USB socket aside, plug in the
Micro-USB cable into the Micro-USB charging port on
the body of the flashlight. Connect the Micro-USB cable
with a USB power supply or computer USB port or a
vehicle charging adapter to charge. The LED indicator
will light up in red to show the charging is in processing.
Fully charging three depleted 18650 batteries will take
more than 10 hours. When the flashlight is fully charged
the LED indicator will turn green.
LOW BATTERY WARNING
When the battery power is low, the power indicator will
start to blink for one minute; If the indicator turns red,
the flashlight will shut off at any time.
ON
ON
OFF
OFF
ON
SUPPORTED BATTERIES
• 3 x 18650 (Please ensure that all the 18650
batteries used in the SR52UT have a button top
configuration or they will not make contact with
terminals in the battery compartment.)
BATTERY INSTALLATION
Ensure batteries are inserted with the positive (+)
end pointing to the head.
WARNING:
• Do not use unsupported batteries with this
flashlight.
• Cannot use flat 18650 batteries.
• Do not mix rechargeable and non-rechargeable
batteries.
• Use caution on high outputs or long runtimes as
flashlight may get hot.
• Do not charge the light when use the
non-rechargeable batteries.
• Do not mix batteries of different types/brands.
• Do not use the batteries without protective boards
SIDE SWITCH
LANYARD HOLE
CHARGING PORT
COVER
INDICATOR
SPECIFICATIONS
LIGHT OUTPUT
AND RUNTIME
STROBE
LED
VOLTAGE
CANDELA
BEAM DISTANCE
BATTERY TYPE
BODY TYPE
WATERPROOF
IMPACT RESISTANCE
DIMENSIONS
WEIGHT
1,100 lumens / 4 hrs
550 lumens / 7.5 hrs
80 lumens / 40 hrs
10Hz
CREE XP-L HI CW
3V to 9V
160,000 cd
800 m/ 2,625 ft
3 x 18650
Type III hard anodized aluminum
IPX8 (up to 2 m)
1 m
L 161.5mm x D 63mm/ 6.3 in x 2.5in
405 g / 14.3 oz (excluding batteries)
(FIG A)
(FIG C)
(FIG B)
All performance claims to ANSI/NEMA FL1-2009 Standard.
V1. AUG 4, 2015 Made in China
TWIST TO REMOVE
