Thank you for purchasing the Olight M3XS-UT
JAVELOT! Please read this manual carefully before
using this product.
M3XS-UT JAVELOT
EXTENDED-RANGE VARIABLE-OUTPUT LED FLASHLIGHT
USER MANUAL
WARRANTY
Within 30 days of purchase: Return to retailer
from which you purchased for repair or replacement.
Within 5 years of purchase: Return to Olight for
repair or replacement.
This warranty does not cover normal wear and tear,
modifications, misuse, disintegrations, negligence,
accidents, improper maintenance, or repair by anyone
other than an Authorized retailer or Olight itself.
Technical Support Inquiries
techsupport@olightworld.com
Customer Service
cs@olightworld.com
Visit www.olightworld.com to see our
complete product line of portable
illumination tools.
INSIDE THE BOX
M3XS-UT Javelot, Holster, Extended Tube, Battery
magazine, (2) O-rings, user manual
SUPPORTED BATTERIES
• If using 3xCR123A batteries. First, insert the batteries
into the battery magazine, then place the battery
magazine into flashlight, finally tighten the tail cap.
Attention that the positive of battery should towards the
flashlight head.
• If using 4xCR123A batteries or 2x18650 batteries,
the extended tube need be assembled to the flashlight
before battery installation.
Attention: 18650 batteries must be with
protected board and protruding positive electrode
(18650 with flat positive electrode are not
suitable for serial nnect)co
BATTERY INSTALLATION (Figure1)
Ensure batteries are inserted with the positive (+)
end pointing to the head.
WARNING:
• Do not use unsupported batteries with
this flashlight.
• Do not mix batteries of different types/brands.
• Do not mix rechargeable and non-rechargeable
batteries.
• Use caution on high outputs or long runtimes as
flashlight may get hot.
APR 10, 2015 MADE IN CHINA
Figure1
CR123A
Battery Magazine
3 x CR123A
18650 18650
OR
CR123A CR123A C R123A CR123A
4 x CR123A
2 x 18650
Gripper
Tail switch
Tail cap
Extended Tube
Low Battery Indicator
Side Switch
CR12 3A
Note: testing done with 3 x CR123A batteries(3.0V, 1500mAh）
HOW TO OPERATE ( )Figure2
a) Fully press then release the tail swith to turn on or off the light, the flashlight always starts at previous mode
set by side switch.
b) While the light is on, every click on the side switch, the brightness level changes to next level as preset
orders of moon – low – medium – high – low.... Holding the side switch over 1 second, the output enters into
strobe of 10HZ.
c) There are 4 speical operations can directly access the frequently-used modes from off status: half press the
tail switch enable momentary on, and twice click the tail switch activates maxium brightness, and triple
click the tail switch activates strobe, hold the side switch then press the tail switch down, the flashlight
turns at moon light.
SPECIFICATIONS
HIGH
MID
LOW
MOONLIGHT
STROBE
LED
VOLTAGE
CANDELLA
BEAM DISTANCE
BATTERY TYPE
BODY TYPE
WATERPROOF
IMPACT RESISTANCE
DIMENSIONS
WEIGHT
1,200 lumens / 5 minutes+
720 lumens / 55 minutes
600 lumens / 1.5 hours
80 lumens / 12 hours
3 lumens / 360 hours
10 Hz / 1,200 lumens
Cree XP-L high Intensity
4v to 12v
250,000 cd
1000 meters / 3281 feet
3 or 4 x CR123A or 2 x 18650
type III hard anodized aluminum
IPX8 (up to 2 meters)
1 meters
L 211mm x (head)D 63mm,(tube)25mm
255 g/ 8.99 oz(excluding batteries)
All performance claims to ANSI/NEMA FL1-2009 Standard.
OUTPUT VS RUNTIME ( Figure 3)
Figure2 User interface
ON
On status
OFF
OFF
Fully press
Fully press
b)
a)
c)
OFF
OFF
High
Strobe
Slightly press
3
Slightly press
2
ON
Momentary Light
Slightly press
1
ON
HOLD FOR 1 SEC
1xClick
HOLD
t
Moonlight
Tail Switch
Side Switch
Run Time ( minute )
100
200
300
400
500
600
700
800
900
1000
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80
1100
1200
1300
Ambient: Temp. 25 Humd 55℃ . %RH
Battery: 3 x @CR123A 1500mAh Olight
High
lumen
