Seite 1/7
© 2015 Shure Incorporated
27A27347 (Rev. 2)
WIRED MICROPHONE
PGA27
USER GUIDE
Le Guide de l’Utilisateur
Guia del Usuario
Guida dell’Utente
Руководство пользователя
Bedienungsanleitung
日本語
繁體中文
Manual do Usuário
사용자 가이
Panduan Pengguna
PG ALTA SERIES
TM
3
PGA27
Congratulations on the purchase of a new Shure PG Alta
series microphone. The PG Alta series delivers professional
quality audio at an affordable price, with solutions for
capturing nearly any source, including voice, acoustic
instruments, drums, and amplified electric instruments.
Suitable for live and studio applications, PG Alta microphones
are built to last, and meet the same rigorous quality testing
standards that make all Shure products trustworthy and
reliable.
General Rules for Use
Do not cover any part of the microphone grille with your
hand, as this will adversely affect microphone performance.
Aim the microphone toward the desired sound source
(such as the talker, singer, or instrument) and away from
unwanted sources.
Place the microphone as close as practical to the desired
sound source.
Work close to the microphone for extra bass response.
Use only one microphone to pick up a single sound source.
For better gain before feedback, use fewer microphones.
Keep the distance between microphones at least three
times the distance from each microphone to its source
(“three to one rule”).
Place microphones as far as possible from reflective
surfaces.
Add a windscreen when using the microphone outdoors.
Avoid excessive handling to minimize pickup of mechanical
noise and vibration.
Connecting to a Mixer or Computer
Cables
Use only balanced (three-conductor) cables. Otherwise,
the cable will not carry phantom power to the microphone.
If using an adapter for 6.5mm (1/4") inputs, it must have
tip-ring-sleeve (TRS) contacts.
Computer
To deliver audio directly to a computer, use a USB audio
interface with an XLR microphone input that provides
+48V phantom power, such as the Shure MVi.
USB
XLR
Connecting to a computer using the Shure MVi audio interface
PG Alta Microphones
4
Mixer
When connecting to a mixer, use only balanced, microphone-level inputs with phantom power. Most mixers have a switch
for phantom power, so make sure phantom power is on for that channel.
Phantom Power
All condenser microphones require phantom power to operate. This microphone performs best with a 48 V DC supply (IEC-
61938), but it can operate with lower voltages.
Phantom power is provided by the mixer or audio interface that the microphone is connected to, and requires the use of a
balanced microphone cable: XLR-to-XLR or XLR-to-TRS. In most cases, there is a switch or button to activate the phantom
power. See the user guide for the mixer or interface for additional information.
Operation
Positioning the Microphone
The front of the microphone is marked by the logo.
Position this side toward the sound source.
Mounting the Microphone
Use the supplied shockmount to mount the microphone. To
secure the microphone, place it in the shockmount and tighten
the ring at the bottom.
Proximity Effect
Directional microphones progressively boost bass frequencies
as the microphone is placed in closer proximity to the source.
This phenomenon, known as proximity effect, can be used to
create a warmer, more powerful sound.
