Seite 1/2
M18说明书 尺寸： * 材质：书写纸 物 料 编 码 ：4 5 . 5 m m 1 4 8 m m 3 . 0 0 1 3 .6 0 1 0 . 9 0 0 0
操作说明
产品部件:(见 )Figure 1
规格参数
Specifications
Operational instruction
长 毫 米,直 径 毫米127 23
61.5 ( )克 不带 电池
Cree XM-L 2 LED
光面 杯
4556 坎德 拉
135米
IPX 8
尺寸
重量
LED
电池
反光 杯
*输出 亮度 及
运行 时间
中心 光强 度
最大 射程
防水
抗冲 击 2 米
CR123A or 18650
材料 铝合 金,表 面 三 级硬 质氧 化
500 / 2流 明 小时
100 / 9流 明 小时
5 / 120 流明 小时
特殊 模式
10暴闪 赫兹
Dimension
Weight
Battery
Reflector
*Output and
Runtime
Peak Beam intensity
Beam Distance
Waterproof
Impact resistance
Material
LED
Special Mode
(L)127mm x (D)23mm
61.5g(without battery)
Cree XM-L 2 LED
Smooth Surface Reflector
4,556 cd
135m
IPX 8
2m
Aluminum body with anti-scratching
type III Hard Anodization
500 lumens /2h
100 lumens /9h
5 lumens /120h
Strobe 10Hz
CR123A or 18650
运行曲线:(见 )Figure 4
Output VS Runtime ( )See Figure 4
1.电池安装：(见 )Figure 2
2.使用手电:(见 )Figure 3
2.Operate the flashlight: ( )See Figure 3
1.Battery Installation:
( )See Figure 2
Product parts
( )See Figure1
按照图所示装入电池,电池正极
朝向手电头部。
Thank you for purchasing Olight products.
Please read the manual carefully before
using this product this manual is for M18
Maverick.
M18 Maverick( M18 for short) is a super
brightness LED flashlight specially
designed for tactical applications, it is
extended from Olight’s S20 Baton but
better. M18 is assigned striking stainless
steel bezel, tail forward push switch and
friend tactical user interface, besides , it is
equipped with the latest in CREE XM-L2
LED, highly optimized small window
smooth reflector, which raise light
intensity up by 80%,and make the output
reach 500 lumens.
M18 can be powered by 2xCR123A or
RCR123A or 1x 18650 batteries it
includes high efficiency constant current
circuit and precise light-thermal balance
program which ensure high brightness
but long run time. The structure is
designed under the idea of simplicity,
light, innovation and reliability so that it is
very solid and durable. Olight produced
various accessories (such as weapon
mount, filter, remote controller) to
improve its value. It is a perfect choice for
government agencies, law enforcement,
military applications, hunting, outdoor
and much more.
In sert the batte ry into th e fla shlig ht,
re fe r to Fig ure2 the ba tter y posi ti ve ,
to ward s li g ht he ad .
a) Side switch in head controls output,
three brightness levels with “low-
medium-high” change by circle. Hold
the button to activate strobe.
b) Multi-functional tail forward push
switch. lightly press tail cap switch will
output momentary light, and retain the
modes set by side switch, while a triple
click /triple press of the tail cap switch
jumps to Strobe, further hard press of
the tail cap switch loosen the chosen
modes. Under the state of power-on,
hard press turns off the light.
Note: Quickly double click the switch to
activate high output; Quickly triple click
the switch to activate strobe; while
release to quit.
Push down the switch to confirm the
output (high or strobe), but the side
switch will be locked out then.
the output (Strobe/High) will not be
memorized under this status.
感谢您购买 手电筒，在Olight LED
使用前请详细阅读说明书，本说
明书 适用 于 独行侠。M18
M18 M18独行 侠(简称 ）是为战术
应用设计的强光 手电。它源LED
于 但更优 ， 增加 富OLIGHT S20 M18
有攻击性的不锈钢头部、尾部战
术开关以及新的战术操作用户界
面； 装配 最新 、CREE XM-L2 LED
高度优化小口径光面反光杯，输
出峰 值光 强提升 , 光通量 光80%
达 流明 。500
M18 2 CR123A RCR123A兼容 节 或 电池,
1 18650节 电池，内置高效率的恒
流驱动电路以及精密光-热平衡控
制程式，在手电输出亮度与运行
时间完美和协；以简约、轻质、
创新、可靠理念设计的结构体坚
实耐用，完善的的配件（枪夹、
滤镜、线控）扩展产品用途，它
适于执法、军警、打猎、户外
等。
a) 开机状态下，头部侧按键改变
输出亮度，每按键一次，输出按
低-中-高顺序改变一次，常按输
出暴闪。
b) 关机状态下，轻按瞬时点亮，
快速连续轻按 次输出高亮，快速2
连续轻按 次输出暴闪，重按下选3
定输出；开机状态下，重按关
机。
备注：在快速连续轻按 次输出2
高亮和快速连续轻按 次输出暴3
闪的情况下,侧按键则锁定,不能
调光,此时输出的亮度不被记
忆。
备注 ：使 用 节 电池测 试 2 1500mAh 3V CR123A
Note:Testing with 2 pieces of 1500mAh 3V CR123A
Olight Technology Co., Limited
Address: 2/F East, Building A, B3 Block,
Fuhai Industrial Park, Fuyong, Bao'an
District, Shenzhen , China 518103
Tel: +86-755-81452608/81452618
Fax: +86-755-81452508
E-mail:service@olightworld.com
www.olightworld.com
深圳市欧莱特科技有限公司
地址 深圳市宝安区福永镇福海工业区:
B3 A区 栋二楼东
电话:0755-81452608/81452618
传真: 0755-81452508
E-mail:service@olightworld.com
www.olightworld.com
Ro HS Made I n Chi na
We Make A Diffe r en c e
EN User ’s manual
中文 用户手册
We Make A Difference
LED FLASHLIGHT
Model:M18 Maverick
CREE XM-L2 LED
Lens
Tough ultra-clear tempering glass,
with anti-reflective coating,
99% transmissivity
钢化 加硬 玻 璃，
双面 镀膜 透过 率, 99%
透镜
Head case
striking stainless steel
头盖 不锈 钢 攻 击 头
Switch
Side tact switch in head
Forward push switch in tailcap
头部 侧按 键 开关
尾部 正向 开 关
开关
中文
ENGLISH 中 文
Battery Magazine/
电池套 x 1
b
at ter y m aga zin e
Packing List /包装清单
M18 Maverick / x 1手电
Manual (This manual) / 说明书
（本说明书）
Warranty Card / 保修卡
Spare O-rings
备用防水圈 x2
Lanyard/ x 1挂绳 Silicon rubber boot
硅胶帽 x 1
Open
OR
18650
+
-
CR123ACR123A
+
-
Battery Magazine/电池套
Battery installation/电池安装
Figure 2
Figure 3 User interface / 用户操作界面
a)
High/高亮
Low/低亮
Medium/中 亮
Strobe/暴 闪
O /开机n status
Hold/长 按
C k/单击lic Side Switch/侧按 键
b)
OFF
OFF/关 机 High/高 亮
Strobe/暴闪
ON
Momentary Light
/瞬时 点 亮
Slightly press/轻 按
1
Slightly press/轻 按
2
3
Slightly press/轻 按
Tail switch/尾 开关
Tail switch/尾 开 关
Tail c /ap 尾 盖
Head/头部
Striking bezel/攻击头
Clip/夹子
Side Switch/侧 按 键
Lanyard Hole /挂 绳孔
Structure Diagram /产品部件
Figure 1
Figure 4 Output VS Runtime/运行曲线
x
x = 1/6 3 (n=0,1,2...)
*nRun Time ( hour )
Output ( lumen )
500
200
0
400
300
100
5
1/6 0.5 1.5 4.5 13 39 120
Output ( lumen )
0 1/6 0.5 1.5 4.5 13 39 120
Run Time ( hour )
500
200
0
400
300
100
5
x = 1/6 3 (n=0,1,2...)
*n
Medium
High
Low
Battery: 2 x CR123A @3V 1500mAh Olight
Medium
High
Low
Battery: 1 x 18650@3V 2600mAh SAMSUNG
2
29
9
