Jøtul F 600
Installation and Operating Instructions for USA/Canada 2
Jøtul F 600
Manual Version P10
Kindly save these instructions for future references.
2
USA/CANADA
Standards
The Jøtul F Firelight solid fuel heater has been tested 600
and listed to :
U.S. Standards: ANSI/UL 737 and ANSI/UL 1482.
Canadian Standards:
CAN/ULC-S627-M and CAN/ULC-S628-M00 93
Certified Safety Tests performed and listed by:
Intertek Testing Services, Middleton, Wisconsin U.S.A.
Manufactured by:
Jøtul AS
P.O. Box 1411, Fredrikstad, Norway
and
Jøtul North America, Inc.
55 Hutcherson Drive
Gorham, Maine 04038, USA
Combustion Specifications
Heat Output*: Under specific test conditions, this
heater has been shown to deliver heat ranging from
13,500 to 45,900 BTU’s.
Efficiency*: 63%
CO Emissions: N/A
Pariculate Emissions: 4.1 g/hr
* Default values per previous Federal Register 40 CFR Part
60, Subpart AAA.
EPA validated efficiency and CO values were unavailable
at the time of this printing. These values will be made
available in the manual and on the Jotul website (www.
jotul.us) for your reference in the near future.
Installation and Operation
Instructions for North America
Safety Notice: If this solid fuel room heater is not properly
installed, a house fire may result. For your safety, follow the
installation directions. Contact local building or fire officials
about restrictions and installation inspection requirements
in your area.
This manual describes the installation and operation of the
Jøtul F 6 Firelight non-catalytic wood heater. Read this 00
entire manual before you install and use your new stove.
Save these instructions for future reference.
This wood heater needs periodic inspection and repair for
proper operation. See this manual for specific information.
It is against federal regulations to operate this wood heater
in a manner inconsistent with the operating instructions in
this owner’s manual.
Check Building Codes
When installing, operating and maintaining your
Jøtul F Firelight woodstove, follow the guidelines 600
presented in these instructions, and make them available
to anyone using or servicing the stove.
Your city, town, county or province may require a building
permit to install a solid fuel burning appliance.
In the U.S., the National Fire Protection Association’s Code,
NFPA 211, Standards for Chimneys, Fireplaces, Vents and
Solid Fuel Burning Appliances, or similar regulations, may
apply to the installation of a solid fuel burning appliance
in your area.
In Canada, the guideline is established by the CSA
Standard, CAN/CSA-B365-M93, Installation Code for Solid-
Fuel-Burning Appliances and Equipment.
Always consult your local building inspector or authority
having jurisdiction to determine what regulations apply
in your area.
This heater meets the 2015 U.S.
Environmental Protection Agency’s
emission limits for wood heaters
manufactured after May 15, 2015.
This heater may not to be sold after
May 15, 2020.
WARNING !
THIS WOOD HEATER HAS A MANUFACTURER-
SET MINIMUM LOW BURN RATE THAT MUST
NOT BE ALTERED. IT IS AGAINST FEDERAL
REGULATIONS TO ALTER THIS SETTING
OR OTHERWISE OPERATE THIS WOOD
HEATER IN A MANNER INCONSISTENT WITH
OPERATING INSTRUCTIONS IN THIS MANUAL.
See Sect. 5.0 of this manual for important information
regarding the safe, proper, and most efficient operation
of your stove.
3
Table of Contents:
Standards, Codes and Safety Notices
Standards and Codes 2 ...................................................................
Safety Notices 3 ...............................................................................
1.0 Installation
1.1 Assembly before Installation 4 ....................................
1.2 Chimney Connector 4 ....................................................
2.0 Chimney Requirements
2.1 Masonry Chimneys 5 ......................................................
2.2 Prefabricated Chimneys 5 ............................................
2.3 Chimney Height 5 ...........................................................
2.4 Wall Pass-throughs .....................................................5
3.0 Connecting to the Chimney
3.1 Masonry Chimney Thimbles 6 ...............................................
3.2 Hearthmount into a Masonry Fireplace 6 ..........................
3.3 Prefabricated Chimneys 6 .......................................................
4.0 Clearances to combustibles
4.1 Floor Protection 7 .....................................................................
4,2 Clearances to Walls and Ceilings 7 ......................................
4.3 Using Shields to reduce Clearances 7 .................................
4.4 Alcove Installation 8 ................................................................
4.5 MobileHome Installation 8 ....................................................
5.0 Operation
5.1 Combustion Efficiency 8 .........................................................
5.2 CO Emissions 8 .........................................................................
5.3 Wood Fuel and Performance 8 ............................................
5.4 Air Flow and Control 8 ............................................................
5.5 Break-in Procedure 9 ..............................................................
5.6 Starting and Maintaining a Fire 9 .......................................
5.7 Creosote Formation and Removal 10 ....................................
5.8 Adding Fuel 10 ............................................................................
6.0 Maintenance
6.1 Annual Stove Inspection 11 .....................................................
6.2 Ash Removal...........................................................................11
6.3 Chimney System 11 ..................................................................
6.4 Enamel Care 11 ..........................................................................
6.5 Glass Care 11 ...............................................................................
6.6 Glass Replacement 11 ...............................................................
6.7 Gaskets ....................................................................................11
7.0 Accessories
Firescreen 12 .......................................................................................
Outside Air Kit 12 ...............................................................................
Floor Bracket Kit............................................................................ 12
Rear Heatshield 12 .............................................................................
Bottom Heatshield 12 .......................................................................
Stove -Top Thermometer ............................................................ 12
Side Door Lock Kit 12 .........................................................................
8.0 Illustrations
Figures 13-14 .............................................................................................
Clearance Chart and Diagrams 16-17 .................................................
Parts Schematic and Listing 18-19 .......................................................
Appendix A (alternate floor protection) 19 .................................
9.0 Warranty Statement .........................................20
USA/CANADA
Safety Notices
• BURN SOLID, NATURAL WOOD FUEL ONLY. DO NOT
BURN ANY OTHER FUEL.
• DO NOT USE CHEMICALS OR FLUIDS TO START A FIRE.
DO NOT BURN GARBAGE OR FLAMABLE FUELS.
• DO NOT USE A GRATE OR ELEVATE THE FIRE. BUILD THE
FIRE DIRECTLY ON THE HEARTH.
• IF THIS ROOM HEATER IS NOT PROPERLY INSTALLED, A
HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE,
FOLLOW THE INSTRUCTIONS IN THIS MANUAL. FAILURE
TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN
PROPERTY DAMAGE, BODILY INJURY, OR LOSS OF LIFE.
• CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT
RESTRICTIONS AND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
• ANY EXISTING CHIMNEY SYSTEM MUST BE INSPECTED
BEFORE INSTALLATION OF THIS APPLIANCE.
• DO NOT CONNECT THIS STOVE TO ANY AIR DISTRIBUTION
DUCT OR SYSTEM.
• EXTREMELY HOT WHILE IN OPERATION! KEEP CHILDREN,
CLOTHING, AND FURNITURE AWAY. CONTACT WILL
CAUSE SKIN BURNS. USE A CHILD GUARD SCREEN TO
PREVENT ACCIDENTAL CONTACT BY SMALL CHILDREN.
• INSTALL SMOKE DETECTORS IN THE LIVING AREA AND
BEDROOMS OF YOUR HOME. TEST THEM REGULARLY
AND INSTALL FRESH BATTERIES TWICE ANNUALLY.
WHEN INSTALLED IN THE SAME ROOM AS THE STOVE,
A SMOKE OR CARBON MONOXIDE DETECTOR SHOULD
BE LOCATED AS FAR FROM THE STOVE AS POSSIBLE TO
PREVENT THE ALARM SOUNDING WHEN ADDING FUEL.
• Avoid creating a low pressure condition in the room
where the stove is operating. Be aware that operation
of an exhaust fan or clothes dryer can create a low
pressure area and consequently promote flow reversal
through the stove and chimney system. In some cases,
the optional Outside Air Kit #154335 can be used to
alleviate this condition. The chimney and building,
however, always work together as a system - provision
of outside air, directly or indirectly to an atmospherically
vented appliance will not guarantee proper chimney
performance. Consult your local Jøtul authorized dealer
regarding specific installation/performance issues.
• Jøtul strongly recommends that this stove be installed
by a professional solid fuel technician, or that you
consult one if you do the work yourself. Also, consult
your insurance company regarding any other specific
requirements.
