Jøtul F 55
Carrabassett
Installation and Operating
Instructions
for the U.S. and Canada
Jøtul F 55 Carrabassett
Wood Stove
The Jøtul F 55 Carrabassett non-catalytic stove
is listed to burn solid wood only. Do not burn
any other fuels.
Read this entire manual before you install
and use this appliance.
Save these instructions for future reference
and make them available to anyone using or
servicing the fireplace insert.
This wood heater requires periodic inspection
and repair for proper operation. See this
manual for specific maintenance information.
It is against federal regulations to operate
this wood heater in a manner inconsistent
with the operating instructions in this
owner’s manual.
2
139473_M F 55 1/20
Accessories
Stove Gloves, pair - #157363
Heavy-duty, flame-retardant with full gauntlet
Spark Screen - #157232
Enjoy the warmth of open door fire-viewing with use of
this custom fit spark screen.
Stove-Top Thermometer - #5002
We recommend the use of a magnetic stove-top
thermometer to monitor the surface temperature of the
stove. The optimum surface temperature range for the
most efficient performance is between 400
0 F - 7000 F
(2050 C - 3160 C).
Outside Air Kit - #157440
This kit includes a plenum assembly which attaches to
the stove bottom. It permits connection of duct work
from an outside source directly to the air intake of the
stove. A direct outside air connection is required for
mobile home installations.
Mobile Home Floor Bracket Kit - #157321
This kit includes two brackets used to fulfill the mobile
home requirement that the stove be secured directly to
the floor.
Blower Kit - #156431
This kit includes components for mounting a
thermostatically controlled 120 cfm blower to the back
of the stove to enhance heat convection into the living
area.
Gasket Kit - #157680
Includes enough gasket material to replace the glass
and door seals.
Installation and Operation
Instructions for USA/Canada
Safety Notice: If this solid fuel room heater is not properly
installed, a house fire may result. For your safety, follow the
installation directions. Contact local building or fire officials
about restrictions and installation inspection requirements
in your area. Save these instructions for future reference.
.
Table of Contents
Accessories ...................................................................................2
Standards and Safety Notices
Standards / Codes 3 ...........................................................................
Safety Notices 4 ..................................................................................
1.0 Installation
1.1. Pre-installation Assembly 5 ....................................................
1.2 Flue Collar Installation 6 ..........................................................
1.3 Flue Collar Heat Shield 6 ..........................................................
1.4 Chimney Connector 6 ...............................................................
2.0 Chimney Requirements
2.1 Masonry Chimneys 7 ...............................................................
2.2 Prefabricated Chimneys 7 .......................................................
2.3 Chimney Height 8 .....................................................................
2.4 Wall Pass-Throughs 8 ...............................................................
3.0 Connecting to the Chimney
3.1 Masonry Chimneys 9 ...............................................................
3.2 Hearthmount into a Masonry Fireplace 9 ...........................
3.3 Prefabricated Chimneys 10 .......................................................
3.4 Mobile Home Requirements 10 ..............................................
4.0 Clearances to Combustibles
4.1 Floor Protection 11 ......................................................................
4.2 Clearances to Walls and Ceilings 11 ........................................
4.3 Using Shields to Reduce Clearances 11 ..................................
4.4 Alcove Installation 12 .................................................................
4.5 Fireplace Clearances, Mantel and Trim ................................ 12
4.6 Clearance Diagrams 13 ..............................................................
5.0 Operation
5.1 Combstion Efficiency 14 .............................................................
5.2 CO Emissions 14 ...........................................................................
5.3 Wood Fuel and Performance 14 ...............................................
5.4 How Your F 55 Works 15 .............................................................
5.5 Controlling the Fire 15 ................................................................
5.6 Air Control / Blower Settings 15 ..............................................
5.7 Break-in Procedure 16 .................................................................
5.8 Starting and Maintaining the Fire 16 .....................................
5-9 Adding Fuel 17 ..............................................................................
5.10 Open Door Fire-viewing 17 .......................................................
5.11 Creosote and the Need for Removal .................................17
5.12 Ash Removal 17 ............................................................................
6.0 Maintenance
6.1 Door Latch 18 ................................................................................
6.2 Glass Care 18 .................................................................................
6.3 General Care 18 ............................................................................
6.4 Gasket Replacement 19 .............................................................
6.5 Glass Replacement 19 ................................................................
6.6 Chimney System 19 ....................................................................
7.0 Appendix
7.1 Blower Installation 20 ................................................................
7.2 Outside Air Kit Installation 22 .................................................
7.3 Mobile Home Floor Bracket 23 ................................................
8.0 Illustrated Part List ...........................................................25
9.0 Warranty Statement 26 ....................................................
3
139473_M F 55 1/20
Standards
The Jøtul F Carrabassett nooon-catalytic heater has 55
been tested and listed to:
U.S: ANSI/UL 1482-2011 and ANSI/UL 737-2011
Canada: CAN/ULC-S627- and ULC-S00 628-93
Certified Safety Tests performed by:
ITS, Intertek Testing Services
Middleton, WI
Manufactured by:
Jøtul North America
55 Hutcherson Drive
Gorham, Maine 04038-2644
WARNING !
THIS WOOD HEATER HAS A MANUFACTURER-
SET MINIMUM LOW BURN RATE THAT MUST
NOT BE ALTERED. IT IS AGAINST FEDERAL
REGULATIONS TO ALTER THIS SETTING
OR OTHERWISE OPERATE THIS WOOD
HEATER IN A MANNER INCONSISTENT WITH
OPERATING INSTRUCTIONS IN THIS MANUAL.
Check Building Codes
When installing, operating and maintaining your
Jøtul F Carrabassett woodstove, follow the guidelines 55
presented in these instructions, and make them available
to anyone using or servicing the stove.
Your city, town, county or province may require a building
permit to install a solid fuel burning appliance.
In the U.S., the National Fire Protection Association’s
Code, NFPA 211, Standards for Chimneys, Fireplaces, Vents
and Solid Fuel Burning Appliances, or similar regulations,
may apply to the installation of a solid fuel burning
appliance in your area.
In Canada, the guideline is established by the CSA
Standard, CAN/CSA-B365-M93, Installation Code for Solid-
Fuel-Burning Appliances and Equipment.
Always consult your local building inspector or authority
having jurisdiction to determine what regulations apply
in your area.
The Jøtul F 55 Carrabassett is approved for use in mobile
homes. Install in accordance with 24 CFR, Part 3280
(HUD).
Combustion Specifications
Jøtul F 55 Carrabassett
Heat Output Range:1 11,600 to 30,400 BTU/hr.
Max. Heat Output: 83,000 BTU/hr.
Heating Capacity:2 Up to 2,300 sq. ft.
Maximum Burn Time:2 Up to 10 hours
Combustion Efficiency:3 76.23%HHV: LHV: 82.37%
CO Emissions:4 133.54 g/hr
Pariculate Emissions:5 3.50 g/hr
Fuel: Up to 18” Logs (457 mm) Front to Back
See the Operation section of this manual for important
information regarding the safe, proper, and most efficient
operation of your stove.
1 results are determined during Heat Output Range
specific emissions tests established by the EPA.
The Maximum Heat Output value is representative of a
more frequent re-fueling cycle than specified in the EPA
High Heat Output test method.
2 Heating Capacity and Maximum Burn Time will vary
depending on design of home, climate, wood type and
operation
3 High Heat Value and Low Heat Value are obtained per
CSA B415.1-10 test method. HHV calculation encompasses
all products of combustion, including H2O condensation.
LHV calculation includes H2O in its vapor state. Simply
put, HHV assumes all the water component is in a liquid
state (condensed) at the end of combustion and that
heat recovered from condensation can be put to use.
4 Carbon Monoxide Emissions rate results from Test
Method CSA B415.1-10.
5. Particulate Emissions rate is obtained using EPA Test
Method 28-5H.
