Jøtul F Castine400
Jøtul F Castine 400
Non-catalytic Wood Stove
Classic and Clean Face
Installation and Operation Instructions
for the United States and Canada
The Jøtul F 400 Castine non-catalytic
stove is listed to burn solid wood only.
Do not burn any other fuels.
Read this entire manual before you
install and use this appliance.
Save these instructions for future
reference and make them available to
anyone using or servicing the fireplace
insert.
This wood heater requires periodic
inspection and repair for proper
operation. See this manual for specific
maintenance information. It is against
federal regulations to operate this
wood heater in a manner inconsistent
with the operating instructions in this
owner’s manual.
2
139680 03 400-R F Castine M9/19
Table of Contents
Combustion Specifications,
Building Codes,
Safety Notices 3 ......................................................................
1.0 Installation
1.1 Assembly Before Installation 4 .............................................
1.2 Flue Collar Reversal 4 ..............................................................
1.3 Chimney Connector 4 .............................................................
2.0 Chimney Requirements
2.1 Masonry Chimneys 4 .............................................................
2.2 Prefabricated Chimneys 5 ......................................................
2.3 Chimney Height 5 ....................................................................
2,4 Wall Pass-Throughs 5 ..............................................................
3.0 Connecting to the Chimney
3.1 Masonry Chimney 6 ...............................................................
3.2 Hearthmount / Fireplaces 6 ..................................................
3.3 Prefabricated Chimneys 6 ......................................................
4.0 Clearances to Combustibles
4.1 Floor Protection 6 .....................................................................
4.2 Clearances to Walls and Ceilings 6 ......................................
4.3 Using Shields to Reduce Clearances 6 ...............................
4.4 Alcove Installation 7 ...............................................................
4.5 Mobile Home Installation 7 .................................................
5.0 Operation
5.1 Combustion Efficiency......................................................... 7
5.2 CO Emissions 7 .........................................................................
5.3 Wood Fuel and Performance 7 .............................................
5.4 Air Flow and Control 8 ............................................................
5.5 Breakin Procedure 8 ................................................................
5.6 Starting / Maintaining the Fire 8 .........................................
5.7 Adding Fuel 9 ............................................................................
6.0 Maintenance
6.1 Ash Removal........................................................................... 9
6.2 Glass Care 9 ...............................................................................
6.3 Glass Removal 9 .......................................................................
7.0 General Maintenance
7.1 Gaskets .................................................................................... 10
7.2 Gasket replacement 10 .............................................................
7.3 Chimney System 10 ...................................................................
8.0 Accessories ..................................................................... 11
9.0 Illustrations
Clearance Diagrams 14 ....................................................................
Clearance Chart 15 ...........................................................................
Figures 16 - 18 .............................................................................................
Parts Diagram and List ................................................................ 19 - 20
Appendix A - Alternate Floor Protection 20 ...............................
10.0 Warranty 21 .............................................................................
Standards
The Jøtul F Castine solid fuel heater has been tested 400
and listed to :
U.S. Standards: ANSI/UL 737 and ANSI/UL 1482.
Canadian Standards:
CAN/ULC-S627-M and CAN/ULC-S628-M00 93
Certified Safety Tests performed by:
Intertek Testing Services, Middleton,
Wisconsin U.S.A.
Manufactured by:
Jøtul North America, Inc.
55 Hutcherson Drive
Gorham, Maine 04038, USA
and
Jøtul AS, P.O. Box 1411, Fredrikstad, Norway
WARNING !
THIS WOOD HEATER HAS A MANUFACTURER-
SET MINIMUM LOW BURN RATE THAT MUST
NOT BE ALTERED. IT IS AGAINST FEDERAL
REGULATIONS TO ALTER THIS SETTING
OR OTHERWISE OPERATE THIS WOOD
HEATER IN A MANNER INCONSISTENT WITH
OPERATING INSTRUCTIONS IN THIS MANUAL.
This heater meets the 2015 U.S.
Environmental Protection Agency’s
emission limits for wood heaters
manufactured after May 15, 2015.
This heater may not be sold
after May 15, 2020.
A French language version of fhis manual is available to
download at www. jotul. ca.
Télécharger la version française de ce manuel à l’adresse
www. jotul.ca.
NOTE: It is normal for a new, painted stove to emit
odor and smoke during initial fires, depending
upon temperatures over time. This is caused by
the curing of the high temperature paint and
manufactureing materials. This condition can be
alleviated by opening a window or door to provide
additional ventilation.
3
139680 03 400-R F Castine 9/19
Safety Notices
• BURN SOLID, NATURAL WOOD FUEL ONLY. DO NOT
BURN ANY OTHER FUEL.
• DO NOT USE CHEMICALS OR FLUIDS TO START A FIRE.
DO NOT BURN GARBAGE OR FLAMABLE FUELS.
• DO NOT USE A GRATE OR ELEVATE THE FIRE. BUILD THE
FIRE DIRECTLY ON THE HEARTH.
• IF THIS ROOM HEATER IS NOT PROPERLY INSTALLED, A
HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE,
FOLLOW THE INSTRUCTIONS IN THIS MANUAL. FAILURE
TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN
PROPERTY DAMAGE, BODILY INJURY, OR LOSS OF LIFE.
• CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT
RESTRICTIONS AND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
• ANY EXISTING CHIMNEY SYSTEM MUST BE INSPECTED
BEFORE INSTALLATION OF THIS APPLIANCE.
• DO NOT CONNECT THIS STOVE TO ANY AIR DISTRIBUTION
DUCT OR SYSTEM.
• EXTREMELY HOT WHILE IN OPERATION! KEEP CHILDREN,
CLOTHING, AND FURNITURE AWAY. CONTACT WILL
CAUSE SKIN BURNS. USE A CHILD GUARD SCREEN TO
PREVENT ACCIDENTAL CONTACT BY SMALL CHILDREN.
• INSTALL SMOKE DETECTORS IN THE LIVING AREA AND
BEDROOMS OF YOUR HOME. TEST THEM REGULARLY
AND INSTALL FRESH BATTERIES TWICE ANNUALLY.
WHEN INSTALLED IN THE SAME ROOM AS THE STOVE,
A SMOKE OR CARBON MONOXIDE DETECTOR SHOULD
BE LOCATED AS FAR FROM THE STOVE AS POSSIBLE TO
PREVENT THE ALARM SOUNDING WHEN ADDING FUEL.
• Avoid creating a low pressure condition in the room
where the stove is operating. Be aware that operation
of an exhaust fan or clothes dryer can create a low
pressure area and consequently promote flow reversal
through the stove and chimney system. In some cases,
the optional Outside Air Kit #154335 can be used to
alleviate this condition. The chimney and building,
however, always work together as a system - provision
of outside air, directly or indirectly to an atmospherically
vented appliance will not guarantee proper chimney
performance. Consult your local Jøtul authorized dealer
regarding specific installation/performance issues.
• Jøtul strongly recommends that this stove be installed
by a professional solid fuel technician, or that you
consult one if you do the work yourself. Also, consult
your insurance company regarding any other specific
requirements.
Check Building Codes
When installing, operating and maintaining your Jøtul F
400 woodstove, follow the guidelines presented in these
instructions, and make them available to anyone using or
servicing the stove.
Your city, town, county or province may require a building
permit to install a solid fuel burning appliance.
In the U.S., the National Fire Protection Association’s Code,
NFPA 211, Standards for Chimneys, Fireplaces, Vents and
Solid Fuel Burning Appliances, or similar regulations, may
apply to the installation of a solid fuel burning appliance
in your area.
In Canada, the guideline is established by the CSA
Standard, CAN/CSA-B365-M93, Installation Code for Solid-
Fuel-Burning Appliances and Equipment.
Always consult your local building inspector or authority
having jurisdiction to determine what regulations apply
in your area.
See Sect. 5.0 of this manual for important information
regarding the safe, proper, and most efficient operation
of your stove.
Combustion Specifications
Jøtul F 400 Castine
Heat Output Range:1 11,300 to 27,800 BTU/hr.
Max. Heat Output: 55,000 BTU/hr.
Heating Capacity:2 Up to 1,500 sq. ft.
Maximum Burn Time:2 Up to 8 hours
EPA Efficiency:3 HHV: 68.29% LHV: 73.78%
CO Emissions:4 101.46 g/hr
Pariculate Emissions:5
3.8 g/hr
Fuel: Up to 20” Logs (508 mm)
.
1 results are determined during specific Heat Output Range
emissions tests established by the EPA.
The Maximum Heat Output value is representative of a more
frequent re-fueling cycle than specified in the EPA High Heat
Output test method.
2 Heating Capacity and Maximum Burn Time will vary
depending on design of home, climate, wood type and
operation
3 EPA Validated Efficiency:
High Heat Value and Low Heat Value are obtained per CSA
B415.1-10 test method. HHV calculation encompasses all
products of combustion, including H2O condensation.
LHV calculation includes H2O in its vapor state. Simply
put, HHV assumes all the water component is in a liquid
state (condensed) at the end of combustion and that heat
recovered from condensation can be put to use.
4 rate results from Test Method Carbon Monoxide Emissions
CSA B415.1-10.
5.
rate is obtained using EPA Test Method Particulate Emissions
28-5H.
