Jøtul F 45 Greenville
Wood Stove
Jøtul F Greenville 45
Installation and Operating Instructions
for USA and Canada
The Jøtul F 45 Greenville non-catalytic stove
is listed to burn solid wood only. Do not burn
any other fuels.
Read this entire manual before you install
and use this appliance.
Save these instructions for future reference
and make them available to anyone using or
servicing the fireplace insert.
This wood heater requires periodic inspection
and repair for proper operation. See this
manual for specific maintenance information.
It is against federal regulations to operate
this wood heater in a manner inconsistent
with the operating instructions in this
owner’s manual.
2
139575 Rev_10 F 45 9/19
Jøtul F Greenville 45
Accessories
Stove Gloves, pair - #157363
Flame-retardant, full length, Black.
Spark Screen - #157638
Enjoy the warmth of open door fire-viewing
with use of this custom fit spark screen.
Stove-Top Thermometer - #5002
We recommend the use of a magnetic stove-top
thermometer to monitor the surface temperature
of the stove.
The optimum surface temperature range for the
most efficient performance is between 400
0 F -
7000 F (2050 C - 3160 C).
Outside Air Kit - #157637
This kit includes a plenum assembly which
attaches to the stove bottom. It permits
connection of duct work from an outside source
directly to the air intake of the stove. A direct
outside air connection is required for mobile
home installations.
Mobile Home Floor Bracket Kit - #157321|
This kit includes two brackets used to fulfill the
mobile home requirement that the stove be
secured directly to the floor.
Blower Kit - #156431
This kit includes components for mounting
a thermostatically controlled 120 cfm blower
to the back of the stove to enhance heat
convection into the living area.
Short Leg Kit - #157636
This kit includes four, 4 1/4” (108 mm) steel legs
which allow stove installation into a fireplace
opening height as low as 26 1/4”. Approved only
for code-approved, masonry fireplace hearth
mount installation.
Table of Contents
Accessories ...................................................................................2
Standards and Safety Notices
Standards / Codes 3 ...........................................................................
Combustion Specifications 3 ...........................................................
Safety Notices 4 ..................................................................................
1.0 Installation
1.1. Unpack the Stove 5 ...................................................................
1.2 Bottom Heat Shield Requirement 5 .....................................
1.3 Short Leg Installation 5 ...........................................................
1.4 Leg Leveller Installation 5 .......................................................
1.5 Flue Collar Orientation 6 .........................................................
1.6 Flue Collar Heat Shield 6 ..........................................................
1.7 Chimney Connector 6 ...............................................................
2.0 Chimney Requirements
2.1 Masonry Chimneys 7 ...............................................................
2.2 Prefabricated Chimneys 7 .......................................................
2.3 Chimney Height 8 .....................................................................
2.4 Wall Pass-Throughs 8 ...............................................................
3.0 Connecting to the Chimney
3.1 Masonry Chimneys 9 ...............................................................
3.2 Hearthmount into a Masonry Fireplace 9 ...........................
3.3 Prefabricated Chimneys 10 .......................................................
3.4 Mobile Home Requirements 10 ..............................................
4.0 Clearances to Combustibles
4.1 Floor Protection 11 ......................................................................
4.2 Clearances to Walls and Ceilings 11 ........................................
4.3 Using Shields to Reduce Clearances 11 ..................................
4.4 Alcove Installation 12 .................................................................
4.5 Fireplace Clearances, Mantel and Trim ................................ 12
4.6 Clearance Diagrams 13 ..............................................................
5.0 Operation
5.1 Combustion Efficiency 14 ..........................................................
5.2 CO Emissions 14 ..........................................................................
5.3 Wood Fuel and Performance 14 ...............................................
5.4 F 45 Functionality 15 ...................................................................
5.5 Air Control / Blower Settings 15 ..............................................
5.6 Controling the Fire 15 .................................................................
5.7 Break-in Procedure 16 .................................................................
5.8 Starting and Maintaining a Fire 16 ........................................
5.9 Adding Fuel 17 .............................................................................
5.10 Open Door Fireviewing 16 ........................................................
5-11 Creosote and the Need for Removal ................................. 17
5.12 Ash Removal 17 ............................................................................
6.0 Maintenance
6.1 Door Latch 18 ................................................................................
6.2 Glass Care 18 .................................................................................
6.3 General Care 18 ............................................................................
6.4 Gasket Replacement 19 .............................................................
6.5 Glass Replacement 19 ................................................................
6.6 Chimney System 20 ....................................................................
6.7 Firebricks .................................................................................20
7.0 Appendix
7.1 Blower Installation 21 ................................................................
7.2 Outside Air Kit Installation 23 .................................................
7.3 Short Leg Installation 23 ...........................................................
7.4 Mobile Home Floor Bracket 24 ................................................
8.0 Illustrated Part List ...........................................................25
9.0 Warranty Statement .....................................................27
3
139575 Rev_10 F 45 9/19
Standards
The Jøtul F Greenville non-catalytic heater has been 45
tested and listed to:
U.S: ANSI/UL 1482-2011 and ANSI/UL 737-2011
Canada: CAN/ULC-S627- and ULC-S00 628-93
Certified Safety Tests performed by:
ITS, Intertek Testing Services
Middleton, WI
Manufactured by:
Jøtul North America
55 Hutcherson Drive
Gorham, Maine 04038-2644
WARNING !
THIS WOOD HEATER HAS A MANUFACTURER-
SET MINIMUM LOW BURN RATE THAT MUST
NOT BE ALTERED. IT IS AGAINST FEDERAL
REGULATIONS TO ALTER THIS SETTING
OR OTHERWISE OPERATE THIS WOOD
HEATER IN A MANNER INCONSISTENT WITH
OPERATING INSTRUCTIONS IN THIS MANUAL.
This heater meets the 2015 U.S.
Environmental Protection Agency’s
emission limits for wood heaters
manufactured after May 15, 2015.
This heater may not be sold
after May 15, 2020.
Check Building Codes
When installing, operating and maintaining your
Jøtul F Greenville woodstove, follow the guidelines 45
presented in these instructions, and make them available to
anyone using or servicing the stove.
Your city, town, county or province may require a building
permit to install a solid fuel burning appliance.
In the U.S., the National Fire Protection Association’s Code,
NFPA 211, Standards for Chimneys, Fireplaces, Vents and Solid
Fuel Burning Appliances, or similar regulations, may apply
to the installation of a solid fuel burning appliance in your
area.
In Canada, the guideline is established by the CSA Standard,
CAN/CSA-B365-M93, Installation Code for Solid-Fuel-Burning
Appliances and Equipment.
Always consult your local building inspector or authority
having jurisdiction to determine what regulations apply in
your area.
The Jøtul Greenville is approved for use in mobile homes. 45
Install in accordance with 24 CFR, Part 3280 (HUD). Follow
the instructions in this manual.
Combustion Specifications
Jøtul F 45 Greenville
Heat Output Range:1 11,600 to 26,500 BTU/hr.
Max. Heat Output: 55,000 BTU/hr.
Heating Capacity:2 Up to 1,500 sq. ft.
Maximum Burn Time:2 Up to 8 hours
EPA Efficiency:3 74.15%HHV: LHV: 80.10%
CO Emissions:4 89.83 g/hr
Pariculate Emissions:5 2.30 g/hr
Fuel: Up to 18” Logs (457 mm) Front to Back
See the Operation section of this manual for important
information regarding the safe, proper, and most efficient
operation of your stove.
1 results are determined during Heat Output Range
specific emissions tests established by the EPA.
The Maximum Heat Output value is representative of a
more frequent re-fueling cycle than specified in the EPA
High Heat Output test method.
2 Heating Capacity and Maximum Burn Time will vary
depending on design of home, climate, wood type and
operation
3 EPA Validated Efficiency:
High Heat Value and Low Heat Value are obtained per
CSA B415.1-10 test method. HHV calculation encompasses
all products of combustion, including H2O condensation.
LHV calculation includes H2O in its vapor state. Simply
put, HHV assumes all the water component is in a liquid
state (condensed) at the end of combustion and that
heat recovered from condensation can be put to use.
4 Carbon Monoxide Emissions rate results from Test
Method CSA B415.1-10.
5. Particulate Emissions rate is obtained using EPA Test
Method 28-5H.
