 JøtulF445
Holliday
CatalyticWoodHeater
Classic and Clean Face Models
Installation and Operating Instructions
for the United States and Canada
JøtulF445
Holliday
The Jøtul F 445 wood stove is listed
to burn solid wood only. Do not burn
any other fuels.
Read this entire manual before you
install and use this appliance.
Save these instructions for future
reference and make them available to
anyone using or servicing this wood
heater.
This wood heater contains a catalytic
combustor that requires periodic
inspection and maintenance for
proper operation. See this manual
for specific maintenance information.
It is against federal regulations to
operate this wood heater in a manner
inconsistent with the operating
instructions in this owner’s manual, or
if the catalytic element is deactivated
or removed.
Une version française de ce manuel est disponible au-
près de votre revendeur et sur le site www. jotul.ca.
130167-1 F 445 Holliday August 2023
2
Table of Contents
CombustionSpecifications,
BuildingCodes,
SafetyNotices............................................................... 3-4
1. Installation
1.1AssemblybeforeInstallation................................. 5
2. Chimney and Connector Requirements
2.1ChimneyConnector................................................ 6
2.2GeneralRequirements............................................ 6
2.3MasonryChimneys................................................. 7
2.4PrefabricatedChimneys......................................... 8
2.5ChimneyHeight..................................................... 8
2.6WallPass-through................................................... 8
3. Connecting to the Chimney
3.1MasonryChimneyThimbles................................... 9
3.2HearthmountintoaMasonryFireplace................. 10
3.3PrefabricatedChimneys......................................... 10
4. Clearances to Combustibles
4.1FloorProtection...................................................... 11
4.2AlternateFloorProtection...................................... 11
4.3ClearancestoWallsandCeilings............................ 12
4.4UsingShieldstoreduceClearances....................... 12
4.5AlcoveInstallation.................................................. 13
ClearanceCharts........................................................... 14-15
4.6MobileHomeInstallation....................................... 16
5. Operation
5.1CombustionEiciency..................................................16
5.2COEmissions.................................................................17
5.3WoodFuelandPerformance.......................................17
5.4StoveControl-FunctionsandSettings........................18
5.5StoveTopThermometer................................................19
5.6UsingtheCombustorMonitor......................................19
5.7StoveBreak-inProcedure..............................................20
5.8StartingandMaintainingaFire.....................................21
5.9CreosoteFormationandRemoval...............................21
5.10AddingFuel.................................................................22
6. Maintenance
6.1AnnualStoveInspection...............................................22
6.2AshRemoval..................................................................22
6.3ChimneySystem..........................................................22
6.4EnamelCare.................................................................23
6.5GlassCare/GlassReplacement.....................................23
6.6Gaskets..........................................................................23
6.7CombustionSystemMaintenance...............................24
6.8CombustorReplacement..............................................24
7. Parts Lists
ExplodedDiagram................................................................26
PartNumbers.......................................................................27
8. Warranty .................................................................... 28-29
Accessories
Thefollowingaccessories,specificallydesignedforthe
JøtulF445woodstove,areavailablefromyourJøtul
authorizeddealer.
Rear Heatshield - 158374
AstoverearheatshieldhasbeenspecificallydesignedfortheJøtul
F445toreduceclearancesotherearofthestovetocombustible
materials.Useoftheheatshield aecttheclearanceodoes not
thesidesoftheappliance.
See pages 14-15forspecificclearancerequirements.Complete
installationinstructionsaresuppliedwiththeheatshield.
Noothertypeofheatshieldmaybeused.
Blower Kit - 156431
Thisthermostatically-controlled,120cfmblowermounts
unobtrusivelytothebackofthestovetoquietlyenhanceheat
convectiontothelivingarea.Thekitincludesinstallationand
operationinstructionsandmustbeinstalledwithRearHeatShield
154332,notincludedinBlowerKit.
Outside Air Kit - 154335
Provision for outside air may be required by your local building
codes.
Theoutsideairkitincludesa3inchadapterusedtoconnectan
airductdirectlytothestovecombustionchamber.Thefollowing
additionalmaterialswillberequired:
A. Theappropriatelengthofmetallicflexpipeforaconduitofthe
outsideair.
B. Arain/weatherresistantcapfortheoutsideofthehouse.
C. Arodentscreen-thatisnolargerthan1/4”(6,4mm)mesh.
Followtheinstructionsprovidedwiththekit.
Pleasebeawarethatprovisionofoutsideairtosupport
combustionwillnotnecessarilyeliminateperformanceissues
associatedwithnegativepressurewithinthehomeorchimney
system.
Floor Bracket Kit - 750304
Useofthefloorbracketkitisrequiredinallmobilehome
installationstosecurethestovetothefloor.
Stove-top Thermometer - 5002
Youcan use amagneticstove-topthermometerinconjunction
withthecatalyticcombustormonitortohelpachieveoptimalstove
performance.
Short Leg Kit - #350074 Thiskitincludesfour,41/4”cast
ironlegswhichreducestoveheightby21/4”.Use of short leg kit
requires a 1.6 R value hearth pad.
Leg Leveler Kit - 156096
Stove Gloves, pair - 157363
Heavyduty,flameretardant,withfullgauntlet.
Universal Gasket Kit - 157050
Thiskitincludesallthegasketmaterialandinstructionsrequiredto
maintainthesealintegrityofyourwoodstove.
Replacement Catalyst - 158287
Combustion Monitor - 226609
130167_1 F 445 Holliday August 2023
3
Standards
TheJøtulF445Hollidaysolidfuelheaterhasbeentestedand
listedtoANSI/UL intheU.S.and1482
ANSIULC-S inCanada.627
CertifiedSafetyTestsperformedby
IntertekTestingServices,Middleton,WIU.S.A.
Manufacturedby
JøtulNorthAmerica,Inc.
55HutchersonDrive
Gorham,Maine04038,U.S.A.
This heater meets the 2020 U.S.
Environmental Protection Agency’s
emission limits for wood heaters
manufactured aer May 15, 2020.
This manual describes the installation and
operation of the Jøtul F 445 catalytic equipped
wood heater. This heater meets the 2020 U.S.
Environmental Protection Agency’s crib wood
emission limits for wood heaters sold aer May
15, 2020. Under specific test conditions, this
heater has been shown to deliver heat at rates
ranging from 13,726 to 35,722 Btu/hr.
Check Building Codes
Yourcity,town,countyorprovincemayrequireabuilding
permittoinstallasolidfuelburningappliance.
In the U.S.,theNationalFireProtectionAssociation’sCode,
NFPA211,Standards for Chimneys, Fireplaces, Vents and
Solid Fuel Burning Appliances,orsimilarregulations,may
applytotheinstallationofasolidfuelburningappliancein
yourarea.
Alwaysconsultyourlocalbuildinginspectororauthority
havingjurisdictiontodeterminewhatregulationsapplyin
yourarea.
Combustion Specifications
Heat Output Range:1 13,726 to 35,722 BTU/hr.(4.0-10.5kW)
  MaxHeatOutput:
55,000 BTU
Heating Capacity:2 Upto 1600 sq. .
Maximum Burn Time:2 Up to 9 hours
EPA Eiciency:3   HHV: LHV: 72%* 78%
CO Emissions:4 .60 g/min.
Particulate Emissions:5 .49 g/hr.
Fuel:Upto20”Logs(508mm)
.
1 Heat Output Rangeresultsaredeterminedduringspecific
emissionstestsestablishedbytheEPA.
2 Heating Capacity and Maximum Burn Timewillvary
dependingondesignofhome,chimney,climate,woodtype
andoperation.
3 EPA Validated Eiciency:
High Heat Value and Low Heat Value eiciencies are
determinedpertheCSAB415.1-10testmethod.Thedierence
betweentheHHVandLHVishowtheenergyintheexhaustgas
watervaporisaccountedfor.
LHVeiciencyassumesallthewatervaporincombustion
gaseswascondensedandtheheatfromsuchwasrecovered
andtransferredtothedwelling.HHVcalculationsdonot
assumeallwatervaporiscondensed,thereforetheHHVvalue
islessthantheLHVvalue.
*MaximumHHVeiciency:77.7%”
TheF445achievedamaximumthermaleiciencyof77.7based
ontheHHVcalculationmethodduringaportionofthe
EPAcertificationtesting.ThatresultisincludedintheEPA
“weightedaverageeiciency”calculationof72%overall
eiciency.The77.7%valueexceedstheminimumrequirement
of75%HHVforthetaxcredit.”
4 Carbon Monoxide Emissionsrateresultsfrom
TestMethodCSAB415.1-10.
5 Particulate Emissions rateisobtainedusing
EPATestMethod28-R.
EPACertifiedEmissionsTestsperformedby
PFS-TECO,Portland,ORU.S.A.
