Seite 1/1
1. An opening hole of 25mm diameter is required on sink top or work top (D) for installation of tap.
2. Slide the rubber O-ring (C) over the threaded tube (B) and up to the base of tap (A).
3. Insert the threaded tube (B) through the hole of sink top or work top (D) and position the tap properly.
4. Slide the rubber O-washer (E) and metal O-washer (F) over the threaded tube (B) and up to the underside
of sink top or work top (D).
5. Screw and fasten the fixing nut (G). Please ensure the fixing nut (G) is tightened securely.
6. Connect the flexi hose (I) with rubber O-washer (H) to threaded tube (B) on one end and the water supply
on the other end.
ETC-E3300 ETC-E3400 ETC-E3600
●Before installation, please ensure that the following work
conditions are adhered to:
-Water temperature between 0 C - 90 C˚ ˚
-Water pressure between 0.05MPa – 1.0MPa. Pressure reducing
valve is necessary if pressure exceeds 1.2MPa
-Avoid major pressure di erences between hot and cold water ff
supply
●Flush pipes thoroughly before and after installation to ensure
water supply is free of any debris.
●Inspect tap fitting and debugged to its best. Do not attempt to
disassemble fitting on your own.
●Use thread sealant tape (PTFE) on any screw joining
connections and ensure all joints are securely tightened.
This . FIAMMA SDN. BHD. will not be held responsible for the use of superseded or voided specifications.
Fabricatoe must check for cut-out accuracy.
specification is subject to change without notice
Stainless Steel Mixer Tap
