SIZE: Adjusts the “size” of the
cymbal engine. Increasing this pa-
rameter will increase decay time
while also affecting the frequency
response of the decay.
DECAY: Crucible’s cymbal mod-
el contains no envelopes or
VCA’s! The DECAY paramter is
acheived by applying a frequency
independent damping constant
to the engine. Turn clockwise to
decrease the amount of damping
applied resulting in longer more
natural decay times.
TONE: Applies frequency de-
pendent damping to the engine.
Turning clockwise will result in a
“brighter” sound.
INPUT: Skip the exciter and inject
audio directly into the EDGE of the
engine. INPUT is parallel to the ex-
citer, so feel free to use them side
by side.
PITCH: Adjusts the “pitch” and
overall spectrum of the engine.
MODEL: ( ) models a curved
plate with a hole in the center,
approximating a cymbal.
( ) is similar to the last
model with amplitude dependent
“ghost transients.”
( ) removes the center hole
from the model and extends pa-
rameter ranges, giving an entirely
new response and feel.
DEFORM: Adjusts the “thickness”
of the modeled cymbal. Increasing
deform will “thin” the model mak-
ing it more “crashy.”
VELOCITY: Modify the velocity of the
exciter.
CRUCIBLE
CURVED PLATE AND CY
The status of these two jacks deter-
mines where the exciter will strike the
engine. A trigger on EDGE or MID will
apply the exciter to the respective posi-
tion. A simultaneous trigger on both, or
a gate on one and a trigger on the other
will excite the “BELL” of the engine.
EXCITE: Adjust the material and
strike angle of the stick. The stick
sound is brightest at the full CCW
position, approximating a ny-
lon tipped drum stick. Increasing
this parameter moves toward a
wood tip. Approaching the full
CW position ïŹ‚attens the attack
angle causing an larger impact
area between the stick and the
engine. This excites more of the
engine expanding the output fre-
quency spectrum, and increasing
amplitude.
CHOKE: Gate input that applies
strong damping to the engine,
causing it to decay immediately.
A minimum damp time is applied
when a trigger is received. Longer
gates will continue to damp the
engine.
Size: 8hp
Depth: 30mm (with cables)
Power: +61mA, -17mA
Audio Input:
100k ohm impedance
20Vpp range
All CV Inputs:
100k ohm impedance
CV inputs sum with knobs. Full sweep is 5V
Gate Inputs:
100k ohm impedance
2V threshold Schmitt Trigger
Audio Output:
220 ohm impedance
20Vpp range
4.0ms latency max
SPECSINTRODUCTION
Can a realistic cymbal sound be synthesized? Can a model be
developed that actually sounds and behaves like a real cymbal?
These are the questions we had to ask ourselves when we set out
to make our next drum module. After many prototypes and a little
serendipity we present Crucible. A true synthesizer that behaves
and sounds like a real cymbal, while offering the otherworldly
ïŹ‚exibility that can only be acheived with a synthesis model.
Crucible doesn’t contain any samples. Every sound it produces
is fully synthesized in real time. Behind the scenes, common digital
synthesis functions like delay lines and digital ïŹlters are arranged
to form an engine that provides the user with separate “Exciter”
and “Model” synthesis blocks. This means Crucible’s settings
approximate the parameters of an actual stick and cymbal making
both classic and experimental programming intuitive and rewarding.
Recreate the sizzle and swell of your favorite kit cymbal then run
your whole mix into the audio input and head into unexplored
territories.
