Seite 1/1
G
A
O
R
L1
L2
OUT
IN
RCV
G
A
O
R
RCV
L1
L2
OUT
GAIN/SATURATION
Turn this control up to add to th input signal. Signal GAIN and SATURA-harmonic saturation
TION are also dependent on the OFFSET and CV LEVEL as well as the input signal amplitude.
Use this control to add warm low end harmonic content thickness and to your input signal.
CV LEVEL ATTENUATOR
Controls the amplitude level for control voltages (CV) applied to the VCA CV input.
Maximum setting will pass control voltages at a 1:1 ratio as long as the CV RESPONSE
control is set to fully LINEAR (LIN). CV LEVEL may need to be turned down a bit for
mixed LIN/EXP and EXP CV RESPONSE settings, unless the extra gain is desired.
OFFSET
Applies up to a +10 volt oset to CV applied to the VCA CV input. OFFSET works as a
volume gain and control as well as providing a positive bias to control voltages patched
into the VCA CV input. The latter is especially useful for taking advantage of the full
voltage swing of bipolar control voltages for through zero modulation.
Setting this control to the center position (5 volts) will pass the input signal to the
output at (no gain) when GAIN/SATURATION is set to the minimum and CV is unity no
applied to the VCA CV input. Center position is also sucient to bias nominal bipolar
signals (+/- 5V) applied to the VCA CV input for .through zero modulation
Increasing the OFFSET beyond position will add up to 2 times gain to the input center
signal. It is possible to add to the input signal when this feature hard clipping distortion
is used in conjunction with the GAIN/SATURATION control and varied CV RESPON-
SE/LEVEL settings.
This control is typically set to minimum (zero volts) when a positive unipolar control
voltage is applied to the VCA CV input and will raise the baseline CV level and gain
when increased in value.
CV RESPONSE
Continuously variable control over the VCA’s from .CV response linear to exponential
Set to LINEAR (LIN) position to pass control voltages applied to the VCA CV input
unaected. Increase this control to add an exponential response to control voltages
applied to the VCA CV input. The processed CV can be accessed for external patching
via the CV OUT jack, described below.
AMPLITUDE is a discrete transistor core VCA with a wide range of waveform saturation and
distortion capability. This module is capable of faithfully reproducing the classic warmth and fat
tones associated with vintage analog synthesizers and pushes that capability to the extreme. A
novel voltage controlled linear to exponential converter is included and can be used to shape
incoming control voltages to the VCA CV input and can be patched out to external modules.
RESPONSE CV INPUT
This input is for the CV RESPONSE with bipolar or unipolar control modulating
voltages.
Use the CV RESPONSE control to tailor the oset of modulation. Center position is
sucient for symmetrical fading between LIN and EXP response with a bipolar signal.
CV LEVEL LED
Indicates amplitude and status of CV applied to the VCA CV input and OFFSET control.
CV RESPONSE LED
Indicates CV RESPONSE status. BLUE is linear (LIN), GREEN is exponential (EXP).
VCA SIGNAL OUTPUT
This is the VCA main output.
VCA
CV
VCA CV INPUT
This is the control voltage input for the VCA for amplitude modulation of the INPUT
signal.
Use the CV LEVEL attenuator to adjust the of the control voltage applied to emphasis
this input.
Use the CV RESPONSE control and/or RCV input to alter the response of the control
voltage.
VCA
CV
SHAPED CV OUTPUT
Direct CV output for signals patched through the VCA CV input and
processed with the CV RESPONSE control and RCV modulation.
IN VCA SIGNAL INPUT
This is the signal input to the VCA. DC coupling allows AMPLITUDE to process
both audio and control voltages.
OUT
CV
OUT
CV
VCA
VCA
PANEL CONTROL
LED INDICATOR
INPUT
OUTPUT
COLOR KEY LEGEND
LINEAR
RESPON
S
E
E
X
P
O
N
E
N
T
I
A
L
R
E
S
P
O
N
S
E
TIME
AMPLITUDE
