KA-5289BS
EN | Instruction manual
PARTS DESCRIPTION
1
2
4
3
Tristar Europe B.V. Jules Verneweg 87
5015 BH Tilburg | The Netherlands | www.tristar.eu
Smartwares S&L Ltd. Meriden House | 6 Great CornbowHalesowen
West Midlands | B63 3AB | United Kingdom | www.tristar.eu
ENInstruction manual
SAFETY
• By ignoring the safety instructions the
manufacturer cannot be held responsible for
the damage.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order to
avoid a hazard.
• Never move the appliance by pulling the cord
and make sure the cord cannot become
entangled.
• The appliance must be placed on a stable,
level surface.
• The user must not leave the device
unattended while it is connected to the supply.
• This appliance is only to be used for
household purposes and only for the purpose
it is made for.
• This appliance shall not be used by children
aged less than 8 years. This appliance can be
used by children aged from 8 years and above
and persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not play
with the appliance. Keep the appliance and its
cord out of reach of children aged less than 8
years. Cleaning and user maintenance shall
not be made by children unless older than 8
and supervised.
• To protect yourself against an electric shock,
do not immerse the cord, plug or appliance in
the water or any other liquid.
• WARNING: In order to avoid overheating,
do not cover the heater.
• WARNING: Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
• Children of less than 3 years should be kept
away unless continuously supervised.
• Do not use the appliance with a programmer,
timer, separate remote-control system or any
other device that switches the heater on
automatically, since a fire risk exists if the
heater is covered or positioned incorrectly.
• Do not use this heater in the immediate
surroundings of a bath, a shower or a
swimming pool.
• Joists, beams and rafters shall not be cut or
notched to install the appliance.
• Please do not install the appliance close to
curtains and other combustible materials. This
could cause a fire.
• The appliance shall, under no circumstances,
be covered with insulating material or similar
material.
• The heater must be installed at least 1,8m
above the floor.
• The heater must not be located immediately
below a socket-outlet.
PARTS DESCRIPTION
1. Heater unit
2. Switch cord
3. Stand
4. Base
BEFORE THE FIRST USE
• Remove all packaging of the device.
• Check if the voltage of the appliance corresponds to the main voltage
of your home. Rated voltage : AC220-240V 50Hz
• Place the base on a flat surface and unscrew the screws.
• Place the rod with the flange on the base, Tighten it with screws.
• Place the plastic cover over the connection of the foot and the rod.
• Place the other two rods on the first rod and tighten these with the
screws, make sure the rod with the plastic collar is mounted at the top.
• Mount the heater on the thin rod and tighten the screw.
• Guide the cable along the rod through the 2 cable guidance clips
downwards. The device is ready for use.
• If the heater is placed on a wall, the rods and the foot are not
necessary.
• Mount the supplied bracket to a solid straight wall.
• Attach the heater to the holder. Keep at least 50 cm free space around
the device.
• Place the heater at least 180 cm above the ground.
USE
• Always plug the device into a grounded outlet.
• Place the device in a place with at least 50 cm free space around the
unit.
• In case of rain or bad weather never use the device, unplug directly
from the outlet and store the appliance in a dry place.
• Make sure that children, people with mental disabilities and pets never
come close to the heater. Never touch the heater, it is very hot, you
can get very seriously injured!
•Important: Please make sure that the device is installed 100%
level. If the device is not level, it will not heat up! This is a safety
precaution to prevent the device heating up when it tips over.
• Pull the switch cord to set the desired heating mode.
• The following table lists the different heat settings. For another
position pull the cord.
• To switch off the device pull the cord several times until the symbol 0
appears.
Symbol Heating mode Output
0 Off 0 watt
1 Low power 650 watt
2 Medium power 1350 watt
3 High power 2000 watt
• The patio heater is not thermostatically controlled and continues to emit
heat until it is switched off. Always keep an eye on the patio heater while
it is switched on.
• Attention! when using the device with a low amperage of the electrical
network, for example when you are at a camping-site. In position 1 it
should be possible to use the device on a low ampera electrical network.
But to shut off the device, the positions 2 and 3 have to be selected, this
can cause an overloaded electrical network.
CLEANING AND MAINTENANCE
• Before cleaning, unplug the appliance and wait for the appliance to cool
down.
• Clean the appliance with a damp cloth. Never use harsh and abrasive
cleaners, scouring pad or steel wool, which damages the device.
• Never clean the heater with water, never immerse it in water or other
liquid.
• Regularly remove dirt and vermin behind the grill of the heater with a
vacuum cleaner.
ENVIRONMENT
This appliance should not be put into the domestic garbage at the
end of its durability, but must be offered at a central point for the recycling
of electric and electronic domestic appliances. This symbol on the
appliance, instruction manual and packaging puts your attention to this
important issue. The materials used in this appliance can be recycled. By
recycling of used domestic appliances you contribute an important push to
the protection of our environment. Ask your local authorities for information
regarding the point of recollection.
Support
You can find all available information and spare parts at www.tristar.eu!
