A+ Server AS -1124US-TNR Quick Reference Guide
Front View & Interface Rear View
DescriptionNo.
1
2
3
4
5
6
7
8
9
Two PCI-E p1-x16 (FH 9.5") Slots
PCI-E p1-x16 (LP) Slot
VGA Port
UID LED
Serial Port
Dedicated LAN for IPMI
Two USB 3.0 Ports
Ultra Riser Networking Slot*
Redundant Power Supply Modules**
Hard Drive Installation
Board Layout
* Check UIO detail from product website
** Redundancy based on configuration and application load
Removing a Hot-Swap Drive Carrier from the Chassis
1. P
handle.
ress the release button on the drive carrier, which will extend the drive carrier
2. Use the drive carrier handle to pull the drive out of the chasiss.
Insta g a Drivellin
1. Insert a drive into the carrier with the PCB side facing down and the connector end
toward the rear of the carrier. Place the drive in the carrier so that the screw holes line
up.
2. The drive carrier has a tool-less design but you also have the option to secure the
drive to the carrier with two M3 screws. These screws are included in the chassis
accessory box.
3. Insert the drive carrier with the disk drive into its bay, keeping the carrier oriented
so that the hard drive is on the top of the carrier and the release button is on the right
side. When the carrier reaches the rear of the bay, the release handle will retract.
4. Push the handle in until it clicks into its locked position.
CPU Installation
Caution
SAFETY INFORMATION
IMPORTANT: See installation instructions and safety warning before
connecting system to power supply.
http://www.supermicro.com/about/policies/safety_information.cfm
WARNING:
To reduce risk of electric shock/damage to equipment, disconnect power
from server by disconnecting all power cords from electrical outlets.
If any CPU socket empty, install protective plastic CPU cap.
WARNING:
Always be sure all power supplies for this system have the same power
output. If mixed power supplies are installed, the system will not operate.
For more information go to : http://www.supermicro.com/support
!
!
!
1. Removing the Processor Force Frame
Use a Torx T20 driver to loosen the screws holding
down Force Frame in the sequence of . The
3-2-1
screws are numbered on the Force Frame next to each
screw hole.
2. Raising the Force Frame 3. Lifting the Rail Frame
5. Inserting the Carrier Frame/CPU Package 6. Lowering the Force Frame 7. Securing the Force Frame
Secure the screws in the order 1-2-3, tightening to
16.1 kgf-cm (14 lbf-in) of torque. The Force Frame
secures both the Rail Frame and CPU Package.
Caution: Tightening must be executed in proper
1-2-3 sequence to avoid causing catastrophic
damage to the socket or CPU Package.
8. The Force Frame Secured
1. Mounting the Heatsink
Screw #1
Screw #2
Screw #3
Force Frame
Rail Frame
PnP Cover Cap
Carrier Frame/
CPU Package
#1 Screw
#2 Screw
#3 Screw
#4 Screw
Processor Installation
2. Securing the Heatsink
Using a diagonal pattern and a Torx T20 driver, tighten the four
heatsink screws evenly to 16.1 kgf-cm (14.0 lbf-in) torque.
4. Removing the External Cap and PnP
Cover Cap
External Cap
PnP Cover Cap
Heatsink Installation
Memory
3
+
DESIGNED IN USA
H12DSU-iN
REV:
1 2
8
9
10
6
4 5
11 12 13 14 15 16
7
No. t nDescrip io
1SXB1 1 : -L s S t P PCI-E 4.0 )A/ B/1C WIO Ri er Card uppor (C U2 x32
2SXB2: S t P PCI-E 4.0 x )WIO-R Riser Card uppor (C U2 16
3SXB3 3 : t S t P PCI-E 4.0 )A/ B/3C Ul ra I/O Riser Card uppor (C U1 x40
4CPU1 NV 0-1 S A 7Me Ports , AT 0-
5S 3.0 9ATA DOM 8-
6CPU2 NV S A 3Me Port 0, AT 10-1
7CPU2 V S A 7NM e Port 1 , AT 14-1
8CPU1 NV 3Me Ports 2-
9CPU2 NV 3Me Ports 2-
10 JBT1 - CMOS Clear
11 CPU2 DI A S tsMM 1-D2 lo
12 CPU2
13 CPU2 DI E otsMM 1-H2 Sl
14 CPU1 DI A S tsMM 1-D2 lo
15 CPU1
16 CPU1 DI E S tsMM 1-H2 lo
HDD1
HDD0
HDD3
HDD2
HDD5
HDD4
HDD7
HDD6
HDD9
HDD8
HDD11
HDD10
(NVMe with optional parts support for SAS/SATA)
CPU1 CPU2
UID 1
1 2 3 4 5 6
UID Button
Universal Information LED
NIC1 LED
Device Activity LED
Power LED
Power Button
Description
No. Description
No.
1
2
3
4
5
6
Release
Button 1
2
9 3 1
67 45 28
JL1
JF1
FAN7
FAN8JF2
P2-DIMMA1
P2-DIMMB1
P2-DIMMA2
P2-DIMMC1
P2-DIMMB2
P2-DIMMD2
P2-DIMMD1
P2-DIMMC2
JVR1
FAN3
FAN4
FAN5
FAN6
P2-DIMMH2
P2-DIMMG2
P2-DIMMH1
P2-DIMMF2
P2-DIMMG1
P2-DIMME2
P2-DIMMF1
P2-DIMME1
P1-DIMMD2
P1-DIMMC2
P1-DIMMC1
P1-DIMMD1
P1-DIMMA1
P1-DIMMA2
P1-DIMMB1
P1-DIMMB2
CPU1CPU2
P1-DIMMG1
P1-DIMMG2
P1-DIMMH1
P1-DIMMF2
P1-DIMMF1
P1-DIMME2
P1-DIMME1
P1-DIMMH2 FAN1
FAN2
LE1
DIMM Module Population equenc S e
W o l , t DI ts t e f g hen in allingst mem ry modu es he MM slo should be popula ed in th ollowin
order MM MM MMC2 MMD2 MM MM MM MMH2 he: DI A2, DI B2, DI , DI , DI E2, DI F2, DI G2, DI , t n
DI A1, DI B1, DI , DI , DI E1, DI F1, DI G1, DI .MM MM MMC1 MMD1 MM MM MM MMH1
•
• A ys use DI s of t s t , s s .lwa DDR4 MM module he ame ype ize and peed
• Mixed MM peed an be in alled Howeve DI s s c st . r, DI s at t of the all MM will run he speed
s t DI .lowes MM
• T he mo herboard suppor an odd number modules (1 Howevet ts of , 3, etc.). r, to e achieve th
bes memory per orman balanced memory popula ion is re ommendedt f ce, a t c .
Pro o a Their Co o M escess rs nd rresponding Mem ry odul
CPU# Cha el nn
1Cha el nn
2Cha el nn
3Cha el nn
4Cha el nn
5Cha el nn
6Cha el nn
7Cha el nn
8
8 DI SMM
CPU1 C2 D2 G2 H2
CPU2 C2 D2 G2 H2
16 MM DI S
CPU1 A2 B2 C2 D2 E2 F2 G2 H2
CPU2 A2 B2 C2 D2 E2 F2 G2 H2
32 MM DI S
CPU1 A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 F1 F2 G1 G2 H1 H2
CPU2 A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 F1 F2 G1 G2 H1 H2
Default Cable Routing
C or on onnect
Bo dar Card/ C n onn ioect
Backplane HDD Ba MC Ca y S bl P/e N
JSLIM1
(M -H12D U-iNB S ) CN 0- L-1 1 CB SAST-1258-85
JSLIM2
(M -H12D U-iNB S ) CN 2- L-2 3 CB SAST-1243-85
SLIM 1,2SAS
( G )AOC-UR 4N4-i4XTS CN3 CN 4- L- -1254 -8, 4 7 CB SAST F 5
JS /JSLIM3-1 LI 2M3-
(M -H12D U-iNB S ) CN 8- L- -1263 -85 9 CB SAST F 5
JSLIM4
(M -H12D U-iNB S ) CN 10-6 11 CB TL-SAS -1260-85
