Seite 1/2

Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Product Diagram (ST8CU824)

Components Function

1Short-Circuit LEDs (8)

• Indicates that the correspondingSolid Red:

USB-A Port has shorted, and that the port has

been deactivated, to protect the connected

device.

• The port will remain deactivated until the

Charging Station is power-cycled.

2Power Button • Used to turn the On or O.Charging Hub

3DC IN 12V • Used to power the .Charging Hub

4USB-A Ports (8)

• Used to charge multiple (max = 8).Devices

• Voltage at the common collector (VCC) = 5V

• Ground (GND) = 5V

• D+ = 2.7V

• D- = 2.0V

8-Port Charging Station for USB Devices | 8x 2.4A

Requirements

For the latest requirements, please visit www.startech.com/ST8CU824

• Phillips Head Screwdriver (Optional)

Installation

Notes: The features a chipset that can detect the required charging Charging Hub

mode of a device, and switch to the proper mode for full-speed charging (e.g. If an

Apple device is connected, it will automatically charge to Apple charging mode

specications).

When charging multiple devices, the may become warm to the touch, Charging Hub

this is normal and will not harm the connected .Device(s)

1. Connect the to an and the other end to the Power Adapter AC Electrical Outlet DC

IN 12V Port Charging Hub on the .

2. Press the to turn the On. Power Button Charging Hub

3. Connect your to the corresponding on the .Device(s) USB-A Ports Charging Hub

Installing the Mounting Brackets (Optional)

Note: Before installing the to the mounting surface, contact a Mounting Bracket

professional. Product mounting should be completed by a certied professional as per

the local safety and building code guidelines.

1. Align the on the with the four Mounting Holes Mounting Bracket Mounting Holes

on the back of the .Charging Hub

2. Insert the (x4) through the and into the Bracket Screws Mounting Bracket

Mounting Holes Charging Hubon the back of the .

3. Tighten the using a , be careful not to Mounting Screws Phillips Head Screwdriver

over-tighten.

Installing the Rubber Feet (Optional)

1. Remove the from the .Rubber Feet Adhesive Strip

2. Align each of the on the back of the close to each of Rubber Feet Charging Hub,

the four corners.

3. Remove the adhesive backing and apply the to the .Rubber Feet Charging Hub

Note: Be careful not to cover the when applying the .Mounting Holes Rubber Feet

1 4

Manual Revision: May 4, 2022 4:11 PM

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

IC Radiation Exposure Statement

This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment. This equipment

should be installed and operated with minimum distance 0.5cm

between the radiator and your body.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to .

www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com

Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com

Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands
