Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: May 25, 2020 4:41 PM
Product Diagram (RJ45SPLITTER)
Component Function
1RJ45 Connector • Connect the to an existing Cable Adapter
Network.
2RJ45 Ports • Allows you to connect up to 2 Network Devices
to an existing .Network
Requirements
For the latest requirements, please visit www.startech.com/RJ45SPLITTER
• Network Devices x 2 (max 2)
• CAT5 Cables x 2
• Existing Network
Installing the Cable Adapter
1. Connect the on the to an RJ45 port on a RJ45 Connector Cable Adapter Network
Device (Ethernet Patch Panel, Wall Outlet, etc.).
Note: The on the combines the signals of 2 connections CAT5 Cable Cable Adapter
over the one .CAT5 Cable
2. Connect a to the on the and the other side to an CAT5 Cable RJ45 Port Cable Adapter
RJ45 port on a .Network Device
3. Repeat step 2 to connect a second to the .Network Device Cable Adapter
2-to-1 RJ45 Splitter Cable Adapter - F/M
Connectivity Diagram
The lays out the following scenario:Connectivity Diagram
Scenario: A company has two oces (A and B). A single CAT5 Ethernet drop connects
Oce B to the network. The company wants to put a network printer and wireless
access point in Oce B. They would like to have a dedicated Ethernet connection for
each device back to the Network Switch in Oce A.
Solution: Cable Adapters By using the two one at each location, the company can
combine two connections to the switch over the existing wiring at Oce A and split
the signal back into two connections at Oce B.
