www.avsl.com 151. 8UK User Manual 59
Wash & Beam
24 x 3W LED Wall Bar
Item ref: 8 151.59 UK
User Manual
Effects bar with 12 high output RGB wash and 12 amber beam LEDs that provide amazing colour washes
and patterns against walls, ceilings or even floors. The alternating RGB and amber LEDs can be controlled
by auto or sound activated modes from preset internal colour sequences. Alternatively, the bar can be
operated remotely by DMX in either 4, 6, 48 and 54 channel modes and connected to more units if a 11,
larger effect is required. Supplied with professional twist and lock power connections and tilt-adjustable
brackets for mounting to walls or ceilings.
In the box:
Your Wash & Beam s ld arrive with you in a single carton in good conditihou on. T carton should contain he
1 x main uni 2 fixing stand/brackets with thumbscrews, 1 x twist and lock UK mains lead and 1 x user t,
guide.
Warning:
To prevent risk of fire or electric shock, do not expo the unit to rain or damp environments. In the event se
of a spillage, disconnect the mains and al w the unit to dry out naturally. Qualified personnel should then lo
check the unit before continuing use.
Please read rough this manual thoroughly before use, any dama th ge
cause by misuse of product will not be covered by warrantd y.
Please do not open cover, contains high volt e. This ag
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 151. 8UK User Manual 59
Placement:
Use the included mounting brackets fix a stand or lighting truss. to to
Use secondar safety fixings if mounting overhead. y
Keep away from damp or dusty environments.
Ensure adequate airflow around the fixture housings.
Ensure ade ate access to controls and connections. qu
Do not aim LED or laser tput directly into line of sight, as this can result in eye injury. ou
Cleaning:
Use a soft cloth with a neutral detergent to clean the casing as required.
Do not use strong solvents for cleaning the unit.
Rear panel controls:
1. Power input (twist and lock)
2. DMX input
3. DMX output
4. Internal microphone
5. Control panel
6. Led display
7. Power output (twist and lock)
Manual control menu:
P ss the re ” buttoMENU n to enter the settings menu.
Press “ ” and UP DOWNbuttons to navigate through various setting functions.
P button confirm the desired setting. ress “ENTER to
www.avsl.com 151. 8UK User Manual 59
DMX mode:
The Wash & Beam can be controll by DMX signal, simply connect the DMX signal source the DMX ed to
input on the unit a balanced XLR lead. Extra fixtures can be controlled by the same DMX signa by vi a l
looping through the DMX o To enter DMX mode, select d001 from the menu and cout uniton the . nfirm
the correct start address and channel selection using the and buttons and by “ ”UP “ ”DOWN “ ”ENTER .
The d on the LED display will begin to flash once it s received the DMX signal from controller. This “ ” the
unit has 4, or 54 DMX channels as indicated in the tables below: 6, 11 48,
4 Channel mode:
Channel
Value
Function and description
1
0 255-
Red dimmer (0- 100%)
2
0 255-
Green dimmer (0- 100%)
3
0 55- 2
Blue dimmer (0- 100%)
4
0 255
Amber beam dimmer (0- 100%)
