www.avsl.com 151.547 User Manual UK
Recharge DJ
LED Derby & PAR Bar with Tripod
Item ref: 1.547 15 UK
User Manual
Ideal for DJ's this complete portable lighting set comprising 2 PAR
lights and 2 Derby's is powered from a rechargeable T-bar with an
internal lithium battery that provides up to 6 hours use without the
need for additional power. Easily controlled via DMX, infra-red
remote control or internal auto and sound-activated programs
selectable from the rear control panel. Each lighting fixture is
angle-adjustable to distribute colour washes and effects around the
room. Supplied with 2.3m telescopic tripod stand and carry bags
making it ideal for transporting to venues and events where power
isn't readily available.
In the box:
Your Recharge should arrive with u i a single carton in good condition. T carton should contain DJ yo n he
1 x T-bar with 2 RGBW PAR cans and 2 LED Derby s attached 1 x 2.3m Tripod Stand, 1 x Remote unit ,
Control, 1 x UK 3m IEC mains lead, 1 x T-Bar Carry Bag, 1 x Tripod Stand Carry Bag and 1 x user manual.
Warning:
To prevent risk of re or electric shock, do not expo the unit to rain or damp environments. In the event fi se
of a spillage, disconnect the mains and al w the unit to dry out naturally. Qualified personnel should then lo
check the unit fore continuing use. be
Please read rough this manual thoroughly b ore use, any dama th ef ge
cause by misuse of product will not be covered by warrantd y.
Please do not open cover, contains high voltage. This
product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service and repair.
www.avsl.com 1.547UK User Manual 15
Placement:
• Open the included tripod stand legs onto the floor ensuring the thumbscrews are tightened and it s ’
set down on a flat stable surface away from walk ys or where it can be easily knocked over. wa
• Attach the T-Bar to the of the stand and tighten the thumbscrew ensuring its secure. top
• Keep the unit away from damp or dusty environments.
• Ensure adequate air- ow around the fixture housings. fl
• Ensure ade ate access tqu o controls and connections.
• Do not aim LED or laser output rectly into line of sight, as this can result in eye injury. di
Cleaning:
• Use a soft cloth with a neutral detergent to clean the casing as required.
• Use a vacuum cleaner to clear venti tion gr of any dust or debris build-ups. la illes
• Do not use strong solvents for cleaning the unit.
Rear panel and controls:
1. Power switch
2. IEC input (110-240 Vac, 50/60 Hz)
3. Earth screw (do not remove)
4. DMX input
5. DMX output
6. Control panel
7. LED display
8. Microphone
9. Battery charge status
Manual control menu:
Press the “ ” buttoMENU n to enter the settings menu.
Press “ ” and “UP DOWN” buttons to navigate through various setting functions.
Press button confirm the desired setting. “ENTER” to
Display
Mode
Function
Description
Aut
AutP
AP01-AP13
PAR auto modes 1- 13
S01-S32
Speed adjust (slow to fast)
AutF
AF01-AF07
Effect auto modes 1-7
S01-S32
Speed adjust (slow to fast)
n00-n09
Motor speed adjust (slow to fast)
1.
2.
3.
4.
5.
6.
7.
8.
9.
www.avsl.com 1.547UK User Manual 15
Autn
An01-An10
PAR and effect auto modes 1- 10
S01-S32
Speed adjust (slow to fast)
n00-n09
Motor speed adjust (slow to fast)
Sou
SouP
SP01-SP13
PAR sound active modes 1- 13
SouF
S 1-SF07 F0
Effect sound active modes 1-7
Soun
Sn01- Sn10
PAR and effect sound active modes 1- 10
Col
Colo
r0 -r255 00
Red dimmer ( w to high) lo
g0 -g255 00
Green dimmer ( w to high) lo
b0 -b255 00
Blue dimmer ( w to high) lo
u0 -u255 00
White dimmer ( w to high) lo
S000-S032
Strobe adjust (slow to fast)
n0 -n009 00
Motor adjust (slow to fast)
DnH
d0 -d512 01
03CH
3CH DMX mode
06CH
6CH DMX mode
15CH
15CH DMX mode
Sla
Slau
Slave mode select
S yS
ASEn
Sn01-Sn04
Sound sensitivity adjust (low to high)
DM mode: X
The Recharge DJ can be controll by DMX ed signal, simply connect the DMX signal source the DMX put to in
on the unit a balanced XLR lead. Extra fixtures can be controlled by the same DMX signa by looping vi a l
through the DMX out on the To ent DMX mode, select A001 from the menu and co e correct unit. er nfirm th
start address using the and buttons and The A on the LED display will begin by “ ”UP “ ”DOWN “ ”ENTER .
to flash once it s received the DMX signal from the controller. This unit has 3, 6 or 15 DMX ch’annels as
indicated in the tables below:
3 Channel:
