Amplifier Manual
Manuel de l’amplificateur
Features: Caractéristiques:
Models: SD300.1, SD600.1, SD500.4, SD800.5
© 2011 Phoenix Gold • www.phoenixgold.com
• High Eciency Class D Topology
• Compact Size for Easy Installation
• High and Low Pass Crossovers
• Robust Unregulated Power Supply
• Surface Mount Component Technology
• Power Supply Filtering eliminates AM/FM interference
• Panel Mounted RCAs
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verication
• High Temperature Plexiglass cover
• Remote subwoofer level control included (SD300.1/SD600.1/SD800.5 Only)
• Topologie de classe D de gamme complète
• Petit format pour faciliter l’installation
• Filtres croisés passe-haut et passe-bas
• Alimentation électrique robuste non réglementée
• Technologie de composant monté en surface
• Filtrage de l’alimentation électrique qui élimine l’interférence AM/FM
• Amplicateurs à couplage RC montés sur des panneaux
• Terminaux d’alimentation et de haut-parleurs à insertion directe
• Vérication du contrôle de la qualité de la précision audio
• Couvercle de plexiglas résistant aux températures élevées
• Niveau de contrôle de passe-bas inclus (SD300.1/SD600.1/SD800.5)
Amplier Owner’s Manual
© 2011 Phoenix Gold • www.phoenixgold.com
SD300.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 18dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohm
Typical Eciency: 70%
Damping Factor: Greater than 200
SD500.4 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High and Low Pass Crossovers: 12dB per Octave
Crossover Range: 40Hz to 400Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 4 ohm Bridged or 2 ohm Stereo
Typical Eciency: 70%
Damping Factor Greater than 200
RMS Power 14.4Vdc ≤ 1% THD 200 x 1 @ 4 ohm
300 x 1 @ 2 ohm
Dynamic Power 14.4Vdc >1% THD 300 x 1 @ 4 ohm
400 x 1 @ 2 ohm
Recommended Fuse Size: 30 amp
Power/Ground Wire Size: 8 Gauge
Dimensions (Includes Mounting Feet): 7.24” L x 6.93” W x 2.0” H
184mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 7.36” L x 6.93” W x 2.0” H
187mm L x 176mm W x 51mm H
RMS Power 14.4Vdc ≤1% THD 75 x 4 @ 4 ohm Stereo
125 x 4 @ 2 ohm Stereo
250 x 2 @ 4 ohm Bridged
Dynamic Power 14.4Vdc >1% THD 90 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
Recommended Fuse Size: 50 amp
Power/Ground Wire Size: 8 Gauge
Dimensions (Includes Mounting Feet): 10.0” L x 6.93” W x 2.0” H
254mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 10.63” L x 6.93” W x 2.0” H
270mm L x 176mm W x 51mm H
Specifications
SD800.5 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >100dB
High Pass Crossovers: 12dB per Octave
Low Pass Crossover: 18dB per Octave
High Pass Crossover Range: 15Hz to 250Hz
Low Pass Crossover Range: 30Hz to 300Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Front and Rear Channels Lowest Load: 4 ohm Bridged or 2 ohm Stereo
Subwoofer Channel Lowest Load: 2 ohm
Typical Eciency: 70%
Damping Factor Greater than 200
Note: All SD ampliers operate correctly up to 14.4 volts. Do not
operate the amplier above 14.4 volts. The amplier will engage its
overvoltage protection, the result is no audio output on one or
more channels.
RMS Power 14.4Vdc ≤1% THD 75 x 4 @ 4 ohm Stereo
125 x 4 @ 2 ohm Stereo
250 x 2 @ 4 ohm Bridged
plus
200 x 1 @ 4 ohm
300 x 1 @ 2 ohm
Dynamic Power 14.4Vdc >1% THD 90 x 4 @ 4 ohm Stereo
150 x 4 @ 2 ohm Stereo
300 x 2 @ 4 ohm Bridged
plus
300 x 1 @ 4 ohm
400 x 1 @ 2 ohm
Recommended Fuse Size: 60 amp
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Mounting Feet): 11.57” L x 6.93” W x 2.0” H
294mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 12.2” L x 6.93” W x 2.0” H
310mm L x 176mm W x 51mm H
SD600.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 18dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Eciency: 70%
Damping Factor: Greater than 200
RMS Power 14.4Vdc ≤ 1% THD 400 x 1 @ 2 ohm
600 x 1 @ 1 ohm
Dynamic Power 14.4Vdc >1% THD 600 x 1 @ 2 ohm
800 x 1 @ 1 ohm
Recommended Fuse Size: 60 amp
Power/Ground Wire Size: 4 Gauge
Dimensions (Includes Mounting Feet): 10.0” L x 6.93” W x 2.0” H
254mm L x 176mm W x 51mm H
Dimensions (Includes Terminals): 10.12” L x 6.93” W x 2.0” H
257mm L x 176mm W x 51mm H
© 2011 Phoenix Gold • www.phoenixgold.com
Amplier Owner’s Manual
INPUT
Connect preamp signal cables from the head unit to these terminals.
CROSSOVER FREQUENCY
Controls the lowpass crossover point for the speaker outputs.
BASS BOOST
Variable bass boost from 0 to +18dB @ 45Hz.
REMOTE LEVEL CONTROL
This port is for connecting the subwoofer remote level control. This allows
up to 20dB of volume adjustment. This is not a bass boost, it controls the
level of the low pass signal.
NOTE: This control is not compatible with the Phoenix Gold LPL44 level
control.
SENS
Used to reach maximum amplier power with a wide variety of headunits.
SUBSONIC CROSSOVER FREQUENCY
Controls the highpass crossover point for the speaker outputs to eliminate
extreme low frequencies.
+12V
This must be connected to the fused positive terminal (+12V) of the car’s
battery. The fuse must be located within 18 inches of the battery.
REMOTE
This must be connected to switched +12V, usually a trigger wire coming
from the head unit or ignition.
GROUND
This must be connected to the negative terminal of the car’s battery or
bolted to a clean, unpainted part of the chassis of the vehicle.
SPEAKER OUTPUTS
Used to connect the amplier to speakers. SD600.1 minimum impedance
is 1 ohm. SD300.1 minimum impedance is 2 ohm.
GROUND REMOTE + 12V
FUSE
30A30A SPEAKER
GROU ND + 12VR
POWER
SENS
MIN MAX
BASS
0dB 18dB
X-OVER
FREQ.
30Hz 300Hz
REMOTE
PROTECT
SUBSONI C
10Hz 55Hz
L
R
INPUT
SD300.1/SD600.1
Monoblo ck Power AmplifierS
NOTE: Visible through the plexiglass cover, a single blue power LED is located in the lower corner of all SD ampliers.
