AMPLIFIER
OWNER’S MANUAL
ELITE
Elite Amplier Owner’s Manual
© 2012 Phoenix Gold • www.phoenixgold.com
ELITE.1
• Class D Topology
• Overbuilt Quad Unregulated Power Supplies
• Handwound Power Supply Transformers
• Isolated Pre-Amp Section
• Crossovers have 41 Detents for Exact Frequency Selection
• Aluminum Shaft Potentiometers
• Panel Mounted RCAs
• Clip Indicators
• Extruded Aluminum Heatsink with Evenow Technology
• Integrated Cooling via Endcap Vents
• Each Amp is Shipped in its Own Soft Felt Protective Cover
• High Temperature Plexiglass Cover
• RMD - Remote Voltage Display Ready
• Remote Level Control with Clip Indicator Included
• Linkable or strappable to an additional Elite.1
• Audio Precision Quality Control Verication
• Power Output Birth Certicate
ELITE.2/4
• Class A/B Topology
• Burr Brown Operational Ampliers
• Monolithic Signal Capacitors
• Massive Dual Package Sanken Output Devices
• Overbuilt Dual Unregulated Power Supplies
• Handwound Power Supply Transformers
• Triple Darlington Output Stage
• Isolated Pre-Amp Section
• Crossovers have 41 Detents for Exact Frequency Selection
• Aluminum Shaft Potentiometers
• Panel Mounted RCAs
• Clip Indicators
• Extruded Aluminum Heatsink with Evenow Technology
• User Adjustable Temperature Controlled Fan Cooling System
• Integrated Cooling via Endcap Vents
• Each Amp is Shipped in its Own Soft Felt Protective Cover
• High Temperature Plexiglass Cover
• RMD - Remote Voltage Display Ready
• Remote Level Control with Clip Indicator Included
• Audio Precision Quality Control Verication
• Power Output Birth Certicate
FEATURES
INTRODUCTION:
Thank you for purchasing a Phoenix Gold Elite amplier, we are condent it will be the nest amplier you have
ever owned.
The Elite ampliers feature only the highest grade of audio components such as Burr Brown op-amps,
Monolithic signal capacitors, and dual-package Sanken output transistors. The result is unparalleled sonic
performance in a mobile audio amplier. With proper installation this amplier is overbuilt to last a lifetime,
thank you for choosing Phoenix Gold.
© 2012 Phoenix Gold • www.phoenixgold.com
INTERNAL BREAKDOWN
High density extruded aluminum heatsink
features 13 grams per mm of mass. Most normal
ampliers have only 6 grams per mm.
High temperature and heavy duty
“Tombstone” balancing resistors
buer the Sanken output devices.
Audiophile monolithic signal capacitors
provide frequency response past 50kHz,
well past the ability of human hearing.
Burr Brown op-amps provide ultra low
distortion and maximum resolution in
the pre-amp circuitry.
All crossovers feature aluminum shaft
precision potentiometers with 41 detents
for exact crossover frequency selection.
The dual package Sanken output devices are usually only
reserved for the highest end of home ampliers. They are
more than 12 times faster compared to most competitor’s
output devices (40MHz vs 3MHz). The Sanken devices are
rated at higher power levels, drive lower impedance loads
better and have 2.5 times the surface mounting area to
transfer heat. The end result is the highest possible sound
quality, dynamic performance and reliability.
Competitor’s “High End”
125w Output Device
Mid to Low Level
100w Output Device
Elite Dual Package Sanken
200w Output Device
Dual Heatsink
MOSFET Clamp
Note: Elite.4 internals are shown above. Elite.1 and .2 internals will vary.
