Seite 1/8
STANDARD EQUIPMENT
BRUSHLESS
19
21
17
15
BRU S H L E S S
19
21
17
15
PXBHS-600
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
Chuck Size: Ø2-13mm Keyless
Chuck Material: Metal
No Load Speed: 0-500 / 0-2,000/min
Impact Rate: 0-8,000 / 0-32,000/min
Torque Settings: 21
Max. Torque: 60Nm
Drilling Capacities: (Drill Bit) Ø32; (Hole Saw) Ø54mm (Timber)
Ø13mm (Metal)
Ø13mm (Masonry)
Weight: 1.37kg
ozito.com.au
0223
Brushless 60Nm Hammer Drill
Auxiliary Handle & Belt Clip
60NM HAMMER
DRILL
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
BRUSHLESS
19
21
17
15
1. Keyless Chuck
2. Torque Adjustment Collar
3. Function Collar
4. Auxiliary Handle
5. Gear Selector
6. Forward/Reverse Button
7. Variable Speed Trigger
8. LED Light
9. Battery Seating
10. Belt Clip
This tool is compatible with all batteries & chargers from the Ozito Power X Change
range.
BRUSHLESS 60NM HAMMER DRILL
BATTERY & CHARGER
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
Installing The Battery Pack
1. Slide the battery into the tool
base until it clicks into place.
Removing The Battery Pack
1. Hold down the battery release
button.
2. Slide the battery out.
Attaching The Side Handle
The side handle provides more control during high torque applications.
Attach it on either side of the tool to suit.
1. Screw the threaded part of the
handle into the side of the tool.
BRUSHLESS
19
21
17
15
1 2 3 4
6
8
9
10
7
5
WARNING! SET THE FORWARD/REVERSE BUTTON
TO ITS CENTRE POSITION BEFORE MAKING
ADJUSTMENTS (EG. INSTALLING DRILL BITS,
CHANGING SPEED, ETC.) TO THE HAMMER DRILL.
THIS LOCKS THE VARIABLE SPEED TRIGGER AND
PREVENTS ACCIDENTAL STARTING.
Forward/Reverse Button
1. To drill or drive screws, push the forward/reverse button towards the left
of the drill.
2. Push the button towards the right of the tool to reverse the rotation.
3. Push the button into the centre position to lock the variable speed trigger
and prevent accidental starting.
Variable Speed Trigger
1. Squeeze the variable speed
trigger to start the tool.
Note: The more the variable speed trigger is depressed, the faster the
drill bit will rotate.
2. Release the trigger to stop
drilling.
Installing A Drill Bit
1. Rotate the chuck collar anti-clockwise to open
the chuck.
2. Insert the drill bit, making sure it
is centred in the chuck.
3. Tighten the chuck by turning the chuck collar
clockwise.
4. Pull on the bit to ensure it is
rmly secured.
Removing A Drill Bit
1. Open the chuck by rotating the
chuck collar anti-clockwise and
remove the drill bit.
WARNING! DO NOT HANDLE ACCESSORIES
WITHOUT GLOVES AS THEY ARE SHARP & CAN
BECOME HOT AFTER USE, POTENTIALLY CAUSING
INJURY.
2. CONTROLS
OPERATION
15 17 191311
15 17 191311
BRU
15
REV
FWD
BRUSHLES
17
15
BRUSHLES
17
15
a.
b.
WARNING! ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY IS REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
