LANCOM Antenna

AirLancer ON-QT60 / ON-QT90

MOUNTING INSTRUCTIONS MOUNTING INSTRUCTIONS MOUNTING INSTRUCTIONS

Important information

Responsible handling of high frequency

In order to comply with the protection requirements of EU Directive 2014/53 and EN 62479 with

regard to the basic restrictions for the safety of persons in electromagnetic ﬁelds and the „FCC Policy

on Human Exposure to Radiofrequency Electromagnetic Fields“, it is necessary to conﬁgure the correct

antenna gain in the WLAN router or WLAN access point.

Important information

Electrical and Electronic Equipment Act

Please do not dispose of electrical and electronic waste in household waste, where it cannot be

recycled. Make sure that your electrical and electronic waste is disposed of in accordance with the

currently valid guidelines of your country.

Important information

Correct handling of antenna cables

Antenna cables are sensitive RF cables. When laying them, it is therefore important to ensure that the

cables are not kinked and are bent as little as possible, as this can result in losses in terms of antenna

performance. Likewise, the antenna cables should not be wound into tight cable loops.

Important information

Antenna gain and termination of unused antenna ports on access points

Unused antenna connections on the access point must be terminated with an enclosed rod antenna.

For indoor access points, the terminating resistor included with the AirLancer AN-RPSMA-NJ adapter

can be used. In addition, the antenna gain must be speciﬁed in the conﬁguration of the access

point.

Mounting kit contents

1 Connection ﬂange ( )A

1 Connection arm ( )B

1 Pole ﬂange / wall bracket ( )C

2 Hexagon head screws M5x25 ( )D

6 Spring washers M5 ( )E

6 Washers M5 ( )F

6 Nuts M5 ( )G

2 Band clamps 2,5“ ( )H

Mounting the antenna ﬂange

Screw the connection ﬂange to the back of the antenna A

housing using the enclosed washers , lock washers and F E

nuts . Make sure that the spring washers are located G E

directly under the nuts.

Then fasten the connecting arm hand-tight to the B

connecting ﬂange using a screw , a spring washer , a D E

washer , and a nut .F G

Make sure that the spring washer is located directly under E

the screw head.

Preparation for wall mounting

If you want to mount the antenna on a wall, use the wall

mount as a drilling template to mark the drill holes for C

wall mounting.

Drill the corresponding holes at the markings and insert

dowels (not included) into them if necessary. Depending on

the wall material and condition, the depth and diameter of

the holes must be adjusted.

Wall mounting of the antenna

Align the wall bracket with the drill holes and fasten it with

suitable screws.

Now fasten the connecting arm , which is already mounted B

on the antenna, to the connecting ﬂange hand-tight using a

screw , a spring washer , a washer , and a nut .D E F G

Make sure that the spring washer is directly under the E

screw head and that the cables of the antenna point

downwards.

Align the antenna according to your wishes and then tighten

the screws of the connection arm with suitable torque.

Pole mounting of the antenna

Position the pole ﬂange at the desired height on a suitable C

pole with sufﬁcient load-bearing capacity and a diameter

between 40 and 64 mm.

Then, as shown in the overview, guide the two band

clamps through the pole ﬂange and around the pole and H C

tighten them after aligning the pole ﬂange.

Then connect the pole ﬂange hand-tight to the connecting C

arm mounted on the antenna by means of an enclosed B

screw , a washer , a spring washer , and a nut .D F E G

Make sure that the spring washer is located directly under E

the screw head.

Align the antenna according to your requirements and then

tighten the screws of the connection arm with suitable

torque.

Technical data ON-QT60 ON-QT90

Frequency range 2,400 - 2,500 MHz, 4,900 - 7,125 MHz

Antenna characteristics

Radiation patterns

Horizontally 2.4 GHz: 60°

Vertically 2.4 GHz: 60°

Horizontally 5 GHz: 60°

Horizontally 2.4 GHz: 95°

Vertically 2.4 GHz: 97°

Horizontally 5 GHz: 99°

Horizontally 5 GHz: 60°

Recommended use Point-to-Multipoint, Sector

VSWR 2.0:1 max.

Gain 2.4 GHz: 7 dBi max.

5 GHz: 7 dBi max.

2.4 GHz: 6 dBi max.

5 GHz: 6 dBi max.

Mechanical Data

Dimensions (mm) 233.7 x 183.7 x 40 (B x H x T)

Weight 900 g (Antenna without mounting kit)

Operating temperature -40 °C to 85 °C

Color Light grey

Material UV resistant plastic

Mounting options Wall and pole mounting, alignable

Cables & Connectors 4x 100 cm ULA100 cable with N-Plug connector

Item

Warranty 2 years for AirLancer and accessories

Item no. 61263 61264

Scope of delivery Antenna, mounting kit for wall and pole mounting
