Seite 1/5
LANCOM Antenna
AirLancer ON-D9a
MOUNTING INSTRUCTIONS
Mounting preparation
Fix the mounting bracket (antenna) to the corresponding
mounting bolts for 0° or 45° orientation at the backside
of the antenna using a hex nut, a flat washer, and a lock
washer per bolt as shown in the diagram.
Connect the mounting bracket (antenna) and the mounting
bracket (middle) using two screws plugged from the inner
side of the brackets. Fasten the connection by first placing a
flat washer and then a lock washer on each bolt. Attach the
hex nuts to the bolts and tighten the nuts hand-tight. Then
proceed with wall- or pole-mounting the antenna.
Wall mounting
Fix the mounting bracket (wall/pole) to a wall able to take
weight using the four supplied screws and dowels. Then
connect the mounting bracket (wall/pole) and the mounting
bracket (middle) of the previously mounted unit using two
screws plugged from the inner side of the brackets. Make
sure that the drain holes on the backside of the antenna
point downwards. Fasten the connection by first placing a
flat washer and then a lock washer on each bolt. Attach the
hex nuts to the bolts and tighten the nuts hand-tight.
Align the antenna according to your needs and tighten all
nuts firmly.
DRAIN HOLES
DRAIN HOLES
Mounting bracket
(wall/pole)
Mounting bracket
(middle)
Mounting bolt
Mounting bolt
Mounting bolt
Mounting bracket
(wall/pole)
Mounting bracket
(middle)
Mounting bracket
(antenna)
Mounting bracket
(antenna)
MOUNTING INSTRUCTIONS
Pole mounting
Fix the mounting bracket (wall/pole) to a suitable pole
4,2 cm - 5,8 cm) using the two supplied screw clamps.
Then connect the mounting bracket (wall/pole) and the
mounting bracket (middle) of the previously mounted unit
using two screws plug+ged from the inner side of the
brackets. Make sure that the drain holes on the backside
of the antenna point downwards. Fasten the connection by
first placing a flat washer and then a lock washer on each
bolt. Attach the hex nuts to the bolts and tighten the nuts
hand-tight. Align the antenna according to your needs and
tighten all nuts firmly.
Connecting to the access point
Antennas of the AirLancer ON-D9a model feature two
antenna connectors for the parallel transmission of two data
streams in combination with a LANCOM 802.11n / 802.11ac
MIMO Access Point. In this case, the following description
applies to each of the antenna connectors. Concerning
overvoltage protection, we strongly recommend the use of
the AirLancer SN-ANT (not included). When connecting to
an Access Point, first connect one end of the supplied cable
to the AirLancer SN-ANT. Then connect the other end to
the Access Point‘s antenna output. For connection to the
antenna, first connect the end of the antenna cable to the
AirLancer SN-ANT. Then connect the other end of the anten-
na cable to the antenna‘s input. You may require an adapter
or adapter cable depending on the type of connector.
Mounting bracket
(wall/pole)
