VAX-1030 & VAX-1100
Multifunction meter for the measurement of direct current circuits
1. GENERAL INFORMATION
Dear customer,
thank you for choosing our product. In the following, we will show you how
to use your product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
The measuring instruments of the VAX series are multimeter which
transmit the measurement results to the display via a wireless 2.4 GHz
technology. A TFT-LCD shows the measured values clearly and enables a
comfortable operation.
The measuring instruments are safeguarded against overvoltage,
undervoltage and overcurrent. In operation with batteries, these devices
can detect automatically the direction of the current ow and displays the
battery capacity in real time.
2. TECHNICAL SPECIFICATIONS
Model VAX-1030 VAX-1100
Measuring range voltage
Resolution voltage
Measuring range current
Resolution current
Relay
0 - 100 V
0,01 V
0 - 100 V
0,01 V
0 - 100 A0 - 30 A
0,01 A
Internal
0,1 A
External (optional)
Measuring range
temperature -20 - 120 °C
0 - 100 %
0 - 200 kW
0,001 W
0 - 2000 AH
0,001 AH
0 - 4000 kWH
0,001 WH
0 - 99 days
1 seconds
± 2 % + 3 digits
± 5 % + 10 digits
5 Hz
Up to 10 m
ca. 0,4 W
Charge indicator
Measuring range power
Resolution power
Measuring range
ampere hours
Resolution ampere hours
Measuring range
watt-hours
Resolution watt-hours
Measuring range time
Resolution time
Accuracy voltage
Accuracy current
Sampling rate
Range, wireless
Power consumption
measuring instrument
Power consumption
display
NCP
OCP
OVP
LVP
delay of
protection settings
0,5 W
0 - 300 A (setting of negative overcurrent protection)
0 - 300 A (setting of overcurrent protection)
0 - 100 V(setting of overvoltage)
0 - 100 V(setting of undervoltage)
0 - 10 s
3. DIMENSIONS IN MM
4. DISPLAY
The measuring instrument can be connected with the display via a cable or
wireless.
If the connection is wireless, there are two opportunities to power the
display. You can use the mUSB port (5 V) or the JST port (8 - 16 V).
mUSB port JST port
