3
EXP500
3
Ausgabe 07.12.2016 Copyright by Joy -IT 2
3
EXP500
Contents
1. Connecons
2. Introducon
3. Basic operaons
3.1 System image le programming
3.2 Serial debugging environment deploying
4. Installing the libraries required
4.1 LED Demo
4.2 Key Demo
4.3 LCD1602 (Purchased Separately) Demo
4.4 PCF8563 RTC Demo
4.5 UART Demo
5. Libraries Installaon for RPi
5.1 Install WiringPi Library
5.2 Install C Library bcm2835
5.3 Install Python Library
5.4 Conguring the interfaces
6. Support
Ausgabe 07.12.2016 Copyright by Joy -IT 3
3
EXP500
1. Connecon
1. Pin header to directly connect with the Raspberry B+, 2B or 3B
2. UART interface: connect UART modules easily like RS232, RS485, USB TO UART (TTL cabel)-
3. 8x I/O interface: connect controlled modules easily via I/O
4. SPI interface for SPI selected modules
5. I2C interface for I2C controlled modules
6. LCD interface for HD44780 industry standard lcd modules
7. - - USB to UART, converter with CP2102 chipset (mini usb connecon)
8. Power LED
9. 4x programable LEDs
10. 4x programable buîž©ons
11. Potenometer: contrast control for LCD displays
12. RTC baîž©ery bracket
13. PCF8563: onboard RTC chip
14. 32.768L crystal: RTC crystal
15. CP2102: onboard USB TO UART chip, for debugging
16. CP2102: Jumper ON/OFF
17. RTC: jumper ON/OFF
18. User LEDs jumper for: ON/OFF
19. User keys jumper for: ON/OFF
